Solution structure of the alpha-subunit of human chorionic gonadotropin.

P J Erbel1, Y Karimi-Nejad, T De Beer

  • 1Bijvoet Center, Department of Bio-Organic Chemistry, Utrecht University, The Netherlands.

European Journal of Biochemistry
|March 30, 1999
PubMed
Summary
This summary is machine-generated.

The three-dimensional structure of deglycosylated alpha-subunit human chorionic gonadotropin (hCG) reveals increased disorder and flexibility compared to the intact dimer, due to the absence of beta-subunit interactions.

More Related Videos

Characterization of Glycoproteins with the Immunoglobulin Fold by X-Ray Crystallography and Biophysical Techniques
08:58

Characterization of Glycoproteins with the Immunoglobulin Fold by X-Ray Crystallography and Biophysical Techniques

Published on: July 5, 2018

Stability and Structure of Bat Major Histocompatibility Complex Class I with Heterologous β2-Microglobulin
11:17

Stability and Structure of Bat Major Histocompatibility Complex Class I with Heterologous β2-Microglobulin

Published on: March 10, 2021

Related Experiment Videos

Last Updated: Jun 24, 2026

Optimized Protocol for the Extraction of Proteins from the Human Mitral Valve
09:13

Optimized Protocol for the Extraction of Proteins from the Human Mitral Valve

Published on: June 14, 2017

Characterization of Glycoproteins with the Immunoglobulin Fold by X-Ray Crystallography and Biophysical Techniques
08:58

Characterization of Glycoproteins with the Immunoglobulin Fold by X-Ray Crystallography and Biophysical Techniques

Published on: July 5, 2018

Stability and Structure of Bat Major Histocompatibility Complex Class I with Heterologous β2-Microglobulin
11:17

Stability and Structure of Bat Major Histocompatibility Complex Class I with Heterologous β2-Microglobulin

Published on: March 10, 2021

Area of Science:

  • Structural Biology
  • Biochemistry
  • Hormone Research

Background:

  • Human chorionic gonadotropin (hCG) is a heterodimeric glycoprotein hormone crucial for pregnancy.
  • Understanding the structural dynamics of individual subunits is essential for elucidating hCG function.
  • The alpha-subunit contains a critical cystine knot motif and glycosylation sites influencing stability.

Purpose of the Study:

  • To determine the three-dimensional solution structure of the deglycosylated alpha-subunit of hCG (dg-alpha hCG).
  • To compare the solution structure of free dg-alpha hCG with its crystal structure in the intact dimer.
  • To investigate the impact of beta-subunit absence on the alpha-subunit's conformation and flexibility.

Main Methods:

  • Nuclear Magnetic Resonance (NMR) spectroscopy (2D homonuclear and heteronuclear 1H, 13C) at natural abundance.
  • Distance geometry and simulated annealing protocols using the XPLOR program package.
  • Modeling of the cystine knot motif and protein-carbohydrate interactions using interproton distance restraints and NOEs.

Main Results:

  • The solution structure of dg-alpha hCG is represented by an ensemble of 27 structures, indicating inherent disorder.
  • Compared to the intact dimer's crystal structure, free dg-alpha hCG exhibits increased structural disorder (residues 33-57) and greater flexibility.
  • Distinct backbone conformations near Val76 and Glu77, and altered arrangements of hairpin loops (20-23 and 70-74) were observed in the free subunit.

Conclusions:

  • The absence of beta-subunit interactions significantly increases the structural disorder and flexibility of the alpha-subunit.
  • The beta-N-acetylglucosamine (GlcNAc) residue at Asn78 is tightly associated with the hydrophobic core, shielding it from solvent.
  • These findings highlight the crucial role of subunit interactions in stabilizing the overall hCG structure and function.
