2-Dimensional beamsteering using dispersive deflectors and wavelength tuning.
Trevor Chan1, Evgeny Myslivets, Joseph E Ford
1Department of Electrical and Computer Engineering, University of California, San Diego, CA 92093, USA. tkc@ucsd.edu
Optics Express
|September 17, 2008
Summary
We developed a novel 2D beamscanner controlled by wavelength tuning. This system uses passive dispersive devices for precise optical beam deflection, demonstrating a discrete 10.3 x 11 degrees field of view.
Area of Science:
- Optics and Photonics
- Optical Engineering
Background:
- Beam steering is crucial for optical systems.
- Existing methods often face limitations in compactness or scan range.
Purpose of the Study:
- To introduce a novel 2D beamscanner controlled by wavelength tuning.
- To demonstrate a proof-of-principle for this new beamsteering technology.
Main Methods:
- Utilizing two orthogonally aligned passive dispersive devices for 2D beam deflection.
- Combining an arrayed waveguide grating with a free-space optical grating for demonstration.
- Analyzing an improved system with a virtually imaged phased array and a diffraction grating.
Main Results:
- Achieved a discrete 10.3 x 11 degrees output field of view.
- Demonstrated beam steering across an 8x6 grid of directions within a 40 nm wavelength range.
- An improved compact design offers continuous scan in one dimension and discrete in the other.
Conclusions:
- Wavelength-tuned beamscanning offers a viable approach for 2D optical beam deflection.
- The proposed systems provide a compact and efficient method for beam steering.
- Further development can lead to advanced optical scanning applications.
