Cardiac Loading using Passive Left Atrial Pressurization and Passive Afterload for Graft Assessment
Published on: August 2, 2024
Cardiac output during high afterload artificial lung attachment.
Jeongho Kim1, Hitoshi Sato, Grant W Griffith
1Department of Surgery, University of Michigan, Ann Arbor, Michigan 48109, USA.
Summary
The zeroth harmonic impedance modulus (Z0) effectively predicts changes in cardiac output (CO) during thoracic artificial lung (TAL) attachment. This new method helps assess right ventricular dysfunction under increased afterload conditions.
Area of Science:
- Biomedical Engineering
- Cardiovascular Physiology
- Respiratory Support
Background:
- Thoracic artificial lungs (TALs) can increase right ventricular (RV) afterload, potentially impairing cardiac output (CO).
- Predicting RV dysfunction during TAL attachment remains challenging.
- A reliable method to assess hemodynamic changes is needed.
Purpose of the Study:
- To evaluate the zeroth harmonic impedance modulus (Z0) as a predictor of CO during high afterload TAL attachment.
- To determine if Z0 can predict RV dysfunction under varying pulmonary vascular resistance and attachment modes.
Main Methods:
- The study used four adult sheep groups with varying baseline pulmonary vascular resistance and TAL attachment (parallel or series).
- Pulmonary system hemodynamic data were collected during incremental increases in TAL resistance.
- The relationship between the change in Z0 (DeltaZ0) and the percent change in CO (DeltaCO%) was analyzed.
Main Results:
- A significant correlation was found between DeltaCO% and DeltaZ0 (p<10(-40)) and DeltaZ0 squared (p<10(-4)).
- The predictive relationship was consistent across different pulmonary hemodynamics and attachment modes.
- The derived equation, DeltaCO%=0.215DeltaZ0(2)-7.14DeltaZ0+2.94 (R2=0.82), accurately describes the CO changes.
Conclusions:
- The zeroth harmonic impedance modulus (Z0) is an effective index for predicting cardiac output during thoracic artificial lung attachment.
- Z0 provides a reliable method for assessing hemodynamic status, even with elevated pulmonary vascular resistance.
- This finding aids in managing patients requiring artificial lung support.
