Size-dependent multiple twinning in nanocrystal superlattices.
Sara M Rupich1, Elena V Shevchenko, Maryna I Bodnarchuk
1Department of Chemistry, The University of Chicago, Chicago, Illinois 60637, USA.
Journal of the American Chemical Society
|December 9, 2009
Summary
The size of lead sulfide (PbS) nanocrystal superlattices influences their structure. Larger PbS nanocrystals form multiply twinned superlattices with unique symmetries, while smaller ones do not.
Area of Science:
- Materials Science
- Nanotechnology
- Crystallography
Background:
- Colloidal nanocrystals self-assemble into ordered superlattices.
- The morphology and symmetry of these superlattices are crucial for their properties.
- Understanding factors controlling superlattice formation is key for materials design.
Purpose of the Study:
- To investigate the influence of nanocrystal size on the morphology of lead sulfide (PbS) superlattices.
- To elucidate the mechanisms behind the observed size-dependent structural changes.
- To explore the implications for designing novel materials with tunable properties.
Main Methods:
- Synthesis of monodisperse PbS nanocrystals of varying sizes (<4 nm and >7 nm).
- Self-assembly of PbS nanocrystals into superlattices.
- Characterization of superlattice morphology and symmetry using electron microscopy and diffraction techniques.
Main Results:
- Superlattices formed from large PbS nanocrystals (>7 nm) exhibited multiply twinned face-centered cubic structures with decahedral and icosahedral symmetry.
- These large nanocrystal superlattices displayed crystallographically forbidden five-fold symmetry elements due to multiple twinning.
- Superlattices composed of small PbS nanocrystals (<4 nm) did not show any twinning.
- Twinning energy was found to be strongly size-dependent, decreasing with increasing nanocrystal size.
- Softer interparticle potentials for larger nanocrystals favored the formation of multiply twinned superlattices.
Conclusions:
- Nanocrystal size is a critical determinant of superlattice morphology and twinning behavior.
- The size-dependent twinning energy and interparticle potentials govern the self-assembly outcome.
- This study introduces a new class of multiply twinned materials with potential for tailored interparticle interactions.
