A generalized reference-plane-based calibration method in optical triangular profilometry.

Suochao Cui1, Xiao Zhu

  • 1Institute of Optoelectronics Science and Engineering, Huazhong University of Science and Technology, 1037 Luoyu Road, Wuhan, 430074, China.

Optics Express
|December 10, 2009
PubMed
Summary
This summary is machine-generated.

A new calibration method for optical triangular profilometry is introduced. This technique establishes a linear relationship between height and phase shift for accurate 3D measurements.
