Aberrations of a horizontal-vertical depolarizer.
Applied Optics
|August 20, 2010
Summary
Aberrations in imaging through uniaxial plates and horizontal-vertical (HV) depolarizers are estimated using ray-trace equations. HV depolarizers introduce astigmatism and image doubling, unlike isotropic plates, with image separation depending on retardance variation.
Area of Science:
- Optics
- Materials Science
- Physics
Background:
- Uniaxial birefringent materials exhibit unique optical properties.
- Horizontal-vertical (HV) depolarizers use crossed birefringent wedges for spatial pseudodepolarization.
- Aberrations in optical systems can degrade image quality.
Purpose of the Study:
- To derive third-order aberration estimates for imaging through uniaxial plates and HV depolarizers.
- To analyze the aberrations introduced by HV depolarizers compared to isotropic plates.
- To investigate the factors influencing image separation in HV depolarizers.
Main Methods:
- Utilized ray-trace equations for uniaxial birefringent materials.
- Developed third-order aberration estimates.
- Employed a computer program for exact birefringent ray tracing.
- Generated spot diagrams to validate aberration estimates.
Main Results:
- Identified spherical aberration, astigmatism, and image doubling as principal aberrations in HV depolarizers for on-axis objects.
- Demonstrated that astigmatism and image doubling are introduced by the birefringent wedges in HV depolarizers.
- Showed image separation is proportional to retardance variation, independent of thickness, wedge angle, or refractive indices.
Conclusions:
- Third-order aberration estimates accurately predict imaging performance through uniaxial plates and HV depolarizers.
- HV depolarizers introduce specific aberrations not present in isotropic materials.
- Retardance variation is the key parameter controlling image separation in HV depolarizers.
