Fabricating Reactive Surfaces with Brush-like and Crosslinked Films of Azlactone-Functionalized Block Co-Polymers
Published on: June 30, 2018
Resist free patterning of nonpreferential buffer layers for block copolymer lithography.
Eungnak Han1, Melvina Leolukman, Myungwoong Kim
1Department of Materials Science and Engineering, University of Wisconsin-Madison, Madison, Wisconsin 53706, United States.
ACS Nano
|October 21, 2010
Summary
We developed a direct electron beam patternable buffer layer to control block copolymer domain orientation. This method simplifies creating chemical patterns for advanced material applications.
Area of Science:
- Materials Science
- Nanotechnology
- Polymer Science
Background:
- Block copolymers (BCPs) self-assemble into ordered nanostructures.
- Controlling BCP domain orientation is crucial for nanolithography and device fabrication.
- Existing methods for pattern formation can be complex and multi-step.
Purpose of the Study:
- To design a novel buffer layer for spatially controlling BCP microdomain orientation.
- To integrate bottom-up self-assembly with top-down lithography for simplified patterning.
- To achieve direct, localized control over BCP domain orientation on a substrate.
Main Methods:
- Synthesized a surface-anchored low molecular weight polystyrene-block-poly(methyl methacrylate) (PS-b-PMMA) buffer layer.
- Utilized the PMMA segment for surface anchoring and the PS block at the buffer layer/BCP interface.
- Employed electron beam (e-beam) lithography to pattern the buffer layer, acting as both a resist and a patterning agent.
Main Results:
- The buffer layer successfully induced perpendicular orientation of BCP domains.
- Tuning buffer layer composition (block lengths) created a nonpreferential surface for orientation control.
- E-beam lithography allowed for precise, localized shaving of the buffer layer, spatially defining domain orientation.
- The direct patterning approach significantly reduced the number of steps compared to conventional lithography.
Conclusions:
- A direct electron beam patternable buffer layer offers a simplified route to control BCP domain orientation.
- This approach combines self-assembly and lithography, enabling efficient spatial control of nanostructures.
- The method holds promise for advanced applications requiring precisely patterned BCP films.
