Probe-based Confocal Laser Endomicroscopy of the Urinary Tract: The Technique
Published on: January 10, 2013
Probe-based confocal laser endomicroscopy in double balloon enteroscopy.
Stephan Miehlke1, A Morgner, D Aust
1Center for Digestive Diseases, Cooperation of Internal Medicine, Hamburg, Germany. prof.miehlke@mdz-hamburg.de
This study shows probe-based confocal laser endomicroscopy (pCLE) is feasible and safe for deep small bowel imaging during double balloon enteroscopy (DBE). The technique successfully visualized mucosal architecture and pathology in 96.3% of cases.
Area of Science:
- Gastroenterology
- Endoscopy
- Medical Imaging
Background:
- Probe-based confocal laser endomicroscopy (pCLE) enables in-vivo assessment of gastrointestinal mucosal architecture.
- Double balloon enteroscopy (DBE) allows deep insertion into the small bowel.
- The combination of pCLE with DBE for deep small bowel examination has not been previously investigated.
Purpose of the Study:
- To investigate the feasibility and safety of performing pCLE during DBE.
- To assess the technical success rate of pCLE in the deep small bowel.
- To evaluate the safety profile of the combined pCLE-DBE procedure.
Main Methods:
- DBE was performed using the Fujinon EN-450P5 system.
- pCLE was conducted using a 1.8-mm probe (Cellvizio-GI®) after fluorescein injection.
- Technical success was defined by successful probe advancement and imaging; safety was monitored for adverse events.
Main Results:
- 27 DBE procedures were performed in 16 patients, reaching mean small bowel insertion depths of 255 cm (antegrade) and 130 cm (retrograde).
- Technical success for pCLE was high at 96.3% (antegrade 92.8%, retrograde 100%), with one instance of incomplete probe advancement.
- No adverse events related to pCLE were reported, and small bowel mucosal architecture, including pathological findings, was visualized in all successful procedures.
Conclusions:
- This study demonstrates the first successful and safe application of pCLE in the deep small bowel via DBE.
- pCLE during DBE allows for in-vivo visualization of small bowel mucosal architecture and pathology.
- Further research is warranted to establish the clinical utility of pCLE in managing small bowel diseases.
