Multiplex single molecule counting technology used to generate interleukin 4, interleukin 6, and interleukin 10
Michele Gilbert1, Richard Livingston1, Jackie Felberg1
1R&D Department, Singulex, Alameda, CA 94502, USA.
Analytical Biochemistry
|March 29, 2016
Summary
A new multiplex instrument uses single molecule counting to detect low-abundance protein biomarkers like interleukin 4 (IL-4) and interleukin 10 (IL-10) in human plasma at very low concentrations.
Area of Science:
- Biotechnology and Biomedical Engineering
- Clinical Diagnostics and Biomarker Discovery
Background:
- Accurate detection of biomarkers at picogram per milliliter (pg/ml) concentrations is crucial for understanding health and disease states.
- Multiplex detection of multiple biomarkers from single samples enhances diagnostic accuracy, testing efficiency, and reduces sample volume requirements.
Purpose of the Study:
- To design and construct a multiplex instrument based on single molecule counting technology.
- To assess the instrument's capability in detecting low-abundance proteins and cytokines in human plasma at sub-pg/ml levels.
- To establish 95% reference limits for key cytokines in healthy individuals.
Main Methods:
- Development of a novel multiplex instrument utilizing single molecule counting technology.
- Analysis of 100 healthy human donor plasma samples.
- Quantification of interleukin 4 (IL-4), interleukin 6 (IL-6), and interleukin 10 (IL-10) concentrations.
Main Results:
- The multiplex single molecule counting instrument successfully detected cytokines at sub-pg/ml quantities.
- Established 95% reference limits: IL-4 (<0.61 pg/ml), IL-6 (<6.53 pg/ml), and IL-10 (<1.08 pg/ml).
- Achieved high detection rates: >90% for IL-4 and 100% for IL-6 and IL-10 above the limit of detection.
Conclusions:
- The developed multiplex instrument enables sensitive detection of low-abundance protein biomarkers in human plasma.
- This technology facilitates accurate quantification of cytokines, crucial for early disease detection and monitoring.
- The established reference limits provide a benchmark for clinical interpretation of IL-4, IL-6, and IL-10 levels.
