Electronic hardware design of electrical capacitance tomography systems.
1Department of Electrical Engineering, Petroleum Institute, Abu Dhabi, United Arab Emirates.
Summary
Electrical Capacitance Tomography (ECT) uses advanced electronics for industrial process imaging, enabling faster data acquisition and processing. This technology enhances visualization of fluid flow in sectors like oil and gas.
Area of Science:
- Process Imaging
- Electrical Engineering
- Industrial Applications
Background:
- Electrical tomography techniques are crucial for industrial process imaging, particularly in the oil and gas and chemical refinery sectors.
- Electrical Capacitance Tomography (ECT) offers non-invasive phase differentiation based on permittivity, with recent advancements improving measurement resolution and channel count.
- High throughput and fast data processing are essential for modern industrial applications.
Purpose of the Study:
- To outline the concept and features of recent front-end and back-end electronic circuits for ECT systems.
- To highlight advancements in hardware design for improved ECT performance.
- To discuss techniques for achieving high-speed data acquisition and processing in ECT.
Main Methods:
- Utilizing multiple-excitation capacitance polling for fast data acquisition in ECT systems.
- Implementing a highly parallel Field-Programmable Gate Array (FPGA) based architecture for rapid image reconstruction.
- Reviewing recent hardware designs for enhanced ECT resolution (attofarad range) and channel density.
Main Results:
- Multiple-excitation capacitance polling demonstrates significant potential for achieving high data acquisition speeds.
- The described FPGA architecture enables efficient and fast reconstruction of ECT images.
- Recent ECT systems achieve high frame rates (hundreds of frames per second) and rapid processing (milliseconds per frame).
Conclusions:
- Advanced front-end and back-end electronics are key to the performance of modern ECT systems.
- The discussed techniques, including multiple-excitation capacitance polling and FPGA-based reconstruction, significantly improve ECT capabilities for industrial process monitoring.
- ECT technology, powered by these electronic innovations, is poised for wider adoption in demanding industrial environments.
