Electrocardiogram Acquisition During Remote Magnetic Catheter Navigation.
Jesús E Dos Reis1,2, Paul Soullié1, Alberto Battaglia3,4
1IADI, INSERM, U1254 and Université de Lorraine, Nancy, France.
Annals of Biomedical Engineering
|February 1, 2019
Summary
A novel electrocardiogram (ECG) sensor with short cables significantly reduces signal distortions during remote magnetic navigation cardiac procedures. This innovation improves ECG monitoring, potentially enhancing patient safety and procedure success rates.
Area of Science:
- Biomedical Engineering
- Cardiology
- Medical Instrumentation
Background:
- Electrocardiogram (ECG) acquisition is crucial during cardiac arrhythmia catheter treatments.
- Remote magnetic navigation (RMN) systems use external magnets to guide catheters, but magnet movement induces significant ECG signal distortions via magnetic flux in cables.
Purpose of the Study:
- To introduce and evaluate a novel ECG sensor designed to minimize signal distortions caused by RMN systems.
- To compare the performance of the novel sensor against conventional 12-lead ECG during RMN procedures.
Main Methods:
- A new ECG sensor utilizing short cables and MRI-like technology was developed.
- The sensor was tested in two healthy subjects and a cardiac pathology phantom during simulated RMN operations.
- Quantitative morphological analysis of ECG waves (PR interval, QRS complex, ST-T wave, PQRST wave) was performed.
Main Results:
- The novel sensor demonstrated significantly improved beat-to-beat correlation coefficients compared to conventional ECG in healthy subjects across all measured intervals.
- In pathological ECG morphologies (VT, AT, STE, STD), the proposed sensor maintained high correlation coefficients (95-99%) for the PQRST wave.
- The new sensor effectively reduced magnetic interference, preserving ECG signal integrity.
Conclusions:
- The novel ECG sensor effectively mitigates distortions induced by RMN systems.
- This technology offers potential for improved, uninterrupted patient monitoring during RMN-guided catheter interventions.
- The sensor may enhance the robustness and duration of procedures like ventricular tachycardia ablation.
