Focused Ion Beam Lithography to Etch Nano-architectures into Microelectrodes
Published on: January 19, 2020
Ion beam etching redeposition for 3D multimaterial nanostructure manufacturing.
B X E Desbiolles1, A Bertsch1, P Renaud1
1Laboratory of Microsystems LMIS4, Ecole Polytechnique Fédérale de Lausanne (EPFL), Lausanne, Switzerland.
A new four-step nanofabrication method enables wafer-scale production of 3D multimaterial nanostructures. This technique offers unprecedented material freedom for applications in biosensing, nanofluidics, nanophotonics, and nanoelectronics.
Area of Science:
- Materials Science
- Nanotechnology
- Microfabrication
Background:
- Traditional nanofabrication methods often lack flexibility in material choice and scalability.
- Manufacturing complex 3D nanostructures requires advanced and often multi-step processes.
Purpose of the Study:
- To introduce a novel, simplified fabrication method for creating 3D multimaterial nanostructures.
- To demonstrate the capability of producing features at sub-100-nm dimensions with high material freedom.
- To explore the potential of this method for various advanced applications.
Main Methods:
- Utilizing local sputtering of photoresist sidewalls during ion beam etching.
- Implementing a four-step process for wafer-scale nanostructure manufacturing.
- Employing standard microprocessing tools for fabrication.
Main Results:
- Successfully fabricated 3D multimaterial nanostructures, including nanochannels, nanowalls, and suspended networks.
- Achieved sub-100-nm feature dimensions with diverse material compositions.
- Demonstrated wafer-scale manufacturing capability in a simplified process.
Conclusions:
- The presented method offers a versatile and efficient alternative to traditional nanofabrication techniques.
- This approach opens new avenues for developing advanced devices in biosensing, nanofluidics, nanophotonics, and nanoelectronics.
