Effective decrease of photoelectric emission threshold from gold plated surfaces.

Peter J Wass1, Daniel Hollington1, Timothy J Sumner1

  • 1High Energy Physics Group, Physics Department, Blackett Laboratory, Imperial College London, Prince Consort Road, London SW7 2AZ, United Kingdom.

The Review of Scientific Instruments
|July 1, 2019
PubMed
Summary
This summary is machine-generated.

This study investigates photoelectric emission from gold surfaces for charge neutralization. Researchers found reliable extrinsic quantum yields, suggesting a practical method for applications requiring controlled charge dissipation.

More Related Videos

Preparation and Photoacoustic Analysis of Cellular Vehicles Containing Gold Nanorods
10:46

Preparation and Photoacoustic Analysis of Cellular Vehicles Containing Gold Nanorods

Published on: May 2, 2016

7.3K
Design and Use of a Full Flow Sampling System FFS for the Quantification of Methane Emissions
08:18

Design and Use of a Full Flow Sampling System FFS for the Quantification of Methane Emissions

Published on: June 12, 2016

17.3K

Related Experiment Videos

Last Updated: Jan 22, 2026

Quantifying Bacterial Surface Swarming Motility on Inducer Gradient Plates
05:57

Quantifying Bacterial Surface Swarming Motility on Inducer Gradient Plates

Published on: January 5, 2022

4.2K
Preparation and Photoacoustic Analysis of Cellular Vehicles Containing Gold Nanorods
10:46

Preparation and Photoacoustic Analysis of Cellular Vehicles Containing Gold Nanorods

Published on: May 2, 2016

7.3K
Design and Use of a Full Flow Sampling System FFS for the Quantification of Methane Emissions
08:18

Design and Use of a Full Flow Sampling System FFS for the Quantification of Methane Emissions

Published on: June 12, 2016

17.3K

Area of Science:

  • Materials Science
  • Surface Physics
  • Quantum Mechanics

Background:

  • Charge neutralization of isolated bodies is crucial for various applications.
  • Photoelectric emission from gold and niobium surfaces has been used for charge neutralization.
  • A comprehensive understanding of the photoelectric emission process from gold surfaces is lacking.

Purpose of the Study:

  • To investigate the photoelectric emission properties of gold-plated surfaces relevant to satellite applications.
  • To determine the influence of UV photon energy, power, and angle of incidence on photoemission.
  • To develop a working model for simulating photoelectric emission from gold surfaces.

Main Methods:

  • Studied 4.6 x 4.6 cm² gold-plated surfaces (800 nm thickness, 7-340 nm roughness).
  • Utilized UV sources (4.8-6.2 eV photon energy, 1 nW-1000 nW power) illuminating ~0.3 cm² at 0°-60° incidence angles.
  • Conducted experiments in a vacuum system (~10⁻⁷ mbar) over ~3 years, including bake-out procedures up to 200 °C.

Main Results:

  • Achieved reliable extrinsic quantum yields in the range of 10 ppm-44 ppm.
  • Observed long-term variations in yield lasting several weeks.
  • Demonstrated photoemission with photon energies lower than the nominal gold work function.

Conclusions:

  • Photoelectric emission from gold surfaces provides a viable method for charge neutralization in specific applications.
  • The study provides experimental data and a working model to predict and simulate photoelectric emission under various conditions.
  • Further research can refine the understanding and application of this phenomenon for spacecraft and other sensitive equipment.
