Application of Ultrasound and Shear Wave Elastography Imaging in a Rat Model of NAFLD/NASH
Published on: April 20, 2021
Quantitative shear wave elastography for noninvasive assessment of solid pancreatic masses
Juan Xie1, Hui Liu2, Wen-Sheng Liu3
1Department of Medical Ultrasound, Fudan University Shanghai Cancer Center, Department of Oncology, Shanghai Medical College, Fudan University, Shanghai, China.
Quantitative shear wave elastography (SWE) accurately differentiates solid pancreatic tumors. This non-invasive technique shows higher stiffness in malignant masses, offering a reliable diagnostic tool for pancreas cancer.
Area of Science:
- Medical Imaging
- Diagnostic Technology
- Gastroenterology
Background:
- Pancreatic tumors pose diagnostic challenges.
- Accurate differentiation between benign and malignant masses is crucial for patient management.
- Non-invasive diagnostic methods are highly sought after.
Purpose of the Study:
- To assess the diagnostic efficacy of quantitative shear wave elastography (SWE) in distinguishing solid pancreatic tumors.
- To determine the value of SWE in the differential diagnosis of pancreatic masses.
Main Methods:
- Sixty-six solid pancreatic masses were evaluated using quantitative SWE.
- Shear wave velocity (SWV) measured the stiffness of pancreatic lesions.
- Receiver operating characteristic (ROC) curve analysis was performed to evaluate diagnostic performance.
Main Results:
- Malignant pancreatic masses exhibited significantly higher SWV (3.30±1.22 m/s) compared to benign masses (1.31±0.64 m/s).
- The area under the ROC curve (AUC) was 0.93.
- An SWV cutoff of 1.77 m/s achieved 92.4% accuracy, 90.0% sensitivity, and 96.2% specificity.
Conclusions:
- Quantitative SWE demonstrates significant potential as a diagnostic tool for pancreatic tumors.
- This technique offers objective and quantitative assessment for predicting pancreas malignancy.
- SWE can aid in the non-invasive differential diagnosis of solid pancreatic lesions.
