Solid State Electronic Sensors for Detection of Carbon Dioxide

Detection of carbon dioxide (CO₂) is very important for environmental, health, safety and space applications. We have studied novel multiwall carbon nanotubes (MWCNTs) and an iron oxide (Fe₂O₃) nanocomposite based chemiresistive sensor for detection of CO₂ at room temperature. The sensor has been miniaturized to a chip size (1 cm × 2 cm). Good sensing performance was observed with a wide detection range of CO₂ concentrations (100-6000 ppm). Structural properties of the sensing materials were characterized using Field-Emission Scanning Electron Microscopy, Fourier-Transform Infrared and Raman spectroscopies. The greatly improved sensitivity of the composite materials to CO₂ can be attributed to the formation of a depletion layer at the p-n junction in an MWCNT/iron oxide heterostructure, and new CO₂ gas molecules adhere to the high surface area of MWCNTs due to the concentration gradient. The test results showed that the CO₂ sensor possesses fast response, compact size, ultra-low power consumption, high sensitivity and wide dynamic detection range.
