Background suppressed magnetization transfer MRI.

Peter van Gelderen1, Jeff H Duyn1

  • 1Advanced MRI Section, Laboratory of Functional and Molecular Imaging, National Institute of Neurological Disorders and Stroke, National Institutes of Health, Bethesda, Maryland.

Magnetic Resonance in Medicine
|September 11, 2019
PubMed
Summary
This summary is machine-generated.

This study introduces a novel single-scan method for measuring magnetization transfer (MT) effects in brain tissue. This approach improves the estimation of the semisolid fraction, crucial for understanding brain health and disease.

Keywords:
background suppressionexchangemagnetization transfermyelinstimulated echowhite matter

More Related Videos

Design and Implementation of an fMRI Study Examining Thought Suppression in Young Women with, and At-risk, for Depression
08:42

Design and Implementation of an fMRI Study Examining Thought Suppression in Young Women with, and At-risk, for Depression

Published on: May 19, 2015

11.2K
Simultaneous PET/MRI Imaging During Mouse Cerebral Hypoxia-ischemia
10:35

Simultaneous PET/MRI Imaging During Mouse Cerebral Hypoxia-ischemia

Published on: September 20, 2015

12.7K

Related Experiment Videos

Last Updated: Jan 19, 2026

Interslice Magnetization Transfer Ratio Imaging for Meningioma Detection
01:26

Interslice Magnetization Transfer Ratio Imaging for Meningioma Detection

Published on: May 30, 2025

176
Design and Implementation of an fMRI Study Examining Thought Suppression in Young Women with, and At-risk, for Depression
08:42

Design and Implementation of an fMRI Study Examining Thought Suppression in Young Women with, and At-risk, for Depression

Published on: May 19, 2015

11.2K
Simultaneous PET/MRI Imaging During Mouse Cerebral Hypoxia-ischemia
10:35

Simultaneous PET/MRI Imaging During Mouse Cerebral Hypoxia-ischemia

Published on: September 20, 2015

12.7K

Area of Science:

  • Biophysics
  • Neuroimaging
  • Magnetic Resonance Imaging (MRI)

Background:

  • Brain tissue contains non-water hydrogen atoms in "semisolids" influencing MRI signals via magnetization transfer (MT).
  • Estimating the semisolid fraction using differential MT sensitization is vital for disease detection.
  • Current methods require multiple scans, limiting their utility in motion-sensitive scenarios.

Purpose of the Study:

  • To develop and validate a single-scan approach for quantifying MT effects in brain tissue.
  • To improve the accuracy and efficiency of semisolid fraction estimation in MRI.
  • To overcome limitations of existing multi-scan MT techniques.

Main Methods:

  • Utilized a stimulated echo sequence to create and manipulate water magnetization patterns.
  • Incorporated controlled exchange with semisolids and subsequent water magnetization saturation.
  • Employed reverse exchange and a third excitation pulse to form a stimulated echo for MT signal detection.

Main Results:

  • Successfully acquired MT data in human subjects at 7 Tesla, demonstrating expected time-dependent signal changes.
  • Achieved excellent suppression of background signals unrelated to exchange.
  • Observed a significant reduction in exchange-related signal (~75%) compared to traditional methods due to the two-step exchange process.

Conclusions:

  • Demonstrated the feasibility of observing MT signals in a single MRI acquisition without subtraction.
  • This single-scan method offers advantages for MT measurements in the presence of motion and physiological instabilities.
  • Potential for more robust and efficient assessment of brain tissue composition and disease-related changes.
