Formulation of acyclovir-loaded solid lipid nanoparticles: design, optimization, and in-vitro characterization
Sanaa A El-Gizawy1, Gamal M El-Maghraby1, Asmaa A Hedaya1
1Pharmaceutical Technology Department, Faculty of Pharmacy, Tanta University , Tanta , Egypt.
This study optimized Acyclovir-loaded solid lipid nanoparticles (ACV-SLNs) using a full factorial design. The optimized ACV-SLNs show potential as a stable and effective drug delivery system.
Area of Science:
- Pharmaceutical Sciences
- Nanotechnology
- Drug Delivery
Background:
- Solid lipid nanoparticles (SLNs) offer a promising platform for drug delivery due to their biocompatibility and controlled release properties.
- Acyclovir (ACV) is an antiviral medication requiring effective delivery systems to enhance its therapeutic efficacy.
- Optimization of SLN formulations is crucial for achieving desired physicochemical characteristics and drug release profiles.
Purpose of the Study:
- To design, optimize, and characterize Acyclovir-loaded solid lipid nanoparticles (ACV-SLNs).
- To investigate the impact of surfactant, lipid, and co-surfactant types on ACV-SLN properties.
- To evaluate the physical stability and drug release kinetics of the optimized ACV-SLN formulation.
Main Methods:
- A full factorial design (2^3) was employed to study the effects of independent variables: surfactant type (Tween 80, Pluronic F68), lipid type (Stearic acid, Compritol 888 ATO), and co-surfactant type (Lecithin, Sodium deoxycholate).
- The microemulsion technique followed by ultrasonication was used for nanoparticle preparation.
- Particle size, polydispersity index (PDI), zeta potential, and entrapment efficiency were characterized. Drug release kinetics and stability were also assessed.
Main Results:
- ACV-SLNs exhibited particle sizes ranging from 172-542 nm with PDI values between 0.193 and 0.526.
- Zeta potential ranged from -25.7 to -41.6 mV, indicating good physical stability.
- Entrapment efficiency was between 56.3-80.7%, and drug release best fitted the Higuchi diffusion model. The optimized formulation (F4) contained Compritol, Pluronic F68, and Lecithin.
Conclusions:
- The full factorial design effectively optimized Acyclovir-loaded solid lipid nanoparticles (ACV-SLNs).
- The optimized ACV-SLNs demonstrated favorable physicochemical properties, including good stability and entrapment efficiency.
- These results highlight the potential of the developed ACV-SLNs as a promising drug delivery system.
