Diagonal Method to Measure Synergy Among Any Number of Drugs
Published on: June 21, 2018
Applying synergy metrics to combination screening data: agreements, disagreements and pitfalls
Anna H C Vlot1, Natália Aniceto2, Michael P Menden3
1Department of Chemistry, Centre for Molecular Science Informatics, University of Cambridge, Cambridge, CB2 1EW, UK; Berlin Institute for Medical Systems Biology, Max Delbrück Center for Molecular Medicine in the Helmholtz Association (MDC), 10115, Berlin, Germany.
Abstract:
Synergistic drug combinations are commonly sought to overcome monotherapy resistance in cancer treatment. To identify such combinations, high-throughput cancer cell line combination screens are performed; and synergy is quantified using competing models based on fundamentally different assumptions. Here, we compare the behaviour of four synergy models, namely Loewe additivity, Bliss independence, highest single agent and zero interaction potency, using the Merck oncology combination screen. We evaluate agreements and disagreements between the models and investigate putative artefacts of each model's assumptions. Despite at least moderate concordance between scores (Pearson's r >0.32, Spearman's ρ>0.34), multiple instances of strong disagreement were observed. Those disagreements are driven by, among others, large differences in tested concentrations, maximum response values and median effective concentrations.
Insights
Identifying synergistic drug combinations for cancer treatment is crucial. This study compares four synergy models, revealing significant disagreements despite moderate agreement, highlighting the impact of experimental factors on results.
Area of Science:
- Oncology
- Pharmacology
- Computational Biology
Background:
- Synergistic drug combinations are essential for overcoming cancer monotherapy resistance.
- High-throughput screening is used to identify effective drug combinations.
- Synergy quantification relies on various models with differing assumptions.
Purpose of the Study:
- To compare the behavior of four common synergy models: Loewe additivity, Bliss independence, highest single agent, and zero interaction potency.
- To evaluate model agreement and disagreement using a real-world cancer combination screen dataset.
- To investigate how model assumptions and experimental factors influence synergy quantification.
Main Methods:
- Utilized the Merck oncology combination screen dataset.
- Applied four distinct synergy quantification models: Loewe additivity, Bliss independence, highest single agent, and zero interaction potency.
- Performed statistical analysis to assess model concordance (Pearson's r, Spearman's ρ) and identify discrepancies.
Main Results:
- Observed moderate concordance between models (Pearson's r >0.32, Spearman's ρ>0.34).
- Identified multiple instances of strong disagreement between the four synergy models.
- Disagreements were attributed to variations in tested concentrations, maximum response values, and median effective concentrations.
Conclusions:
- Different synergy models exhibit significant disagreements, impacting the identification of effective cancer drug combinations.
- Experimental factors such as drug concentration and response metrics critically influence synergy model outcomes.
- Careful consideration of model assumptions and experimental design is necessary for accurate synergy assessment in cancer drug discovery.
