Chemical Sectioning for Immunofluorescence Imaging.

Ruixi Chen^1,2, Hongfu Zhou^1,2, Anan Li^1,2

¹Britton Chance Center for Biomedical Photonics, Wuhan National Laboratory for Optoelectronics-Huazhong University of Science and Technology, Wuhan, Hubei 430074, China.

Analytical Chemistry

|June 17, 2021

Summary

This summary is machine-generated.

Immunofluorescence chemical sectioning (IF-CS) enables clear imaging of tissues labeled with common dyes by controlling fluorescence. This new method overcomes limitations of existing techniques for detailed subcellular studies.

More Related Videos

A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections

A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections

Published on: March 30, 2020

Primer for Immunohistochemistry on Cryosectioned Rat Brain Tissue: Example Staining for Microglia and Neurons

Primer for Immunohistochemistry on Cryosectioned Rat Brain Tissue: Example Staining for Microglia and Neurons

Published on: May 12, 2015

Related Experiment Videos

Last Updated: Nov 1, 2025

Author Spotlight: Enhanced Multiplex Immunofluorescent Microscopy Protocol for Neuroscience Research

Author Spotlight: Enhanced Multiplex Immunofluorescent Microscopy Protocol for Neuroscience Research

Published on: June 21, 2024

A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections

A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections

Published on: March 30, 2020

Primer for Immunohistochemistry on Cryosectioned Rat Brain Tissue: Example Staining for Microglia and Neurons

Primer for Immunohistochemistry on Cryosectioned Rat Brain Tissue: Example Staining for Microglia and Neurons

Published on: May 12, 2015

Area of Science:

Biomedical Imaging
Cell Biology
Microscopy

Background:

Conventional imaging methods face trade-offs between speed, resolution, and specimen volume.
Chemical sectioning (CS) improves imaging by selectively activating superficial fluorescence but is limited to pH-sensitive fluorescent proteins.
Existing CS methods cannot be used with commonly employed commercial fluorescent dyes in immunolabeling.

Purpose of the Study:

To develop a novel chemical sectioning (CS) method for immunofluorescence (IF) imaging.
To enable CS imaging for samples labeled with frequently used commercial fluorescent dyes, such as Alexa dyes.
To overcome the limitations of conventional imaging and existing CS techniques for high-resolution tissue analysis.

Main Methods:

Development of immunofluorescence chemical sectioning (IF-CS) utilizing complexation reactions to control Alexa dye fluorescence.
Application of IF-CS to wide-field block-face imaging systems.
Demonstration of 3D submicron-resolution imaging of large immunolabeled tissues.

Main Results:

IF-CS successfully enabled chemical sectioning for tissues labeled with Alexa dyes.
The method eliminated out-of-focus interference in wide-field immunofluorescence imaging.
High-resolution 3D imaging of large immunolabeled tissues was achieved, supporting multicolor imaging.

Conclusions:

IF-CS provides a versatile solution for imaging immunolabeled tissues, overcoming previous limitations.
This technique allows for detailed submicron-resolution 3D imaging of large tissue samples.
IF-CS is expected to significantly advance systematic studies of subcellular architectures in intact biological systems.
