Fragmentation behavior of EDTA complexes under different activation conditions.

Sebastian Beck1

  • 1Department of Chemistry, Humboldt-Universität zu Berlin, Berlin, Germany.

Journal of Mass Spectrometry : JMS
|June 28, 2021
PubMed
Summary

This study details the fragmentation patterns of Ethylenediaminetetraacetic acid (EDTA) and its metal complexes using various mass spectrometry techniques. Characteristic fragmentations reveal trends related to metal size and periodic table location.

Keywords:
CIDEDTAESIHCDIRMPD

More Related Videos

Controlling the Size, Shape and Stability of Supramolecular Polymers in Water
16:24

Controlling the Size, Shape and Stability of Supramolecular Polymers in Water

Published on: August 2, 2012

18.9K
Analysis of Complex Molecules and Their Reactions on Surfaces by Means of Cluster-Induced Desorption/Ionization Mass Spectrometry
07:53

Analysis of Complex Molecules and Their Reactions on Surfaces by Means of Cluster-Induced Desorption/Ionization Mass Spectrometry

Published on: March 1, 2020

7.5K

Related Experiment Videos

Last Updated: Oct 31, 2025

Hydrolysis of a Ni-Schiff-Base Complex Using Conditions Suitable for Retention of Acid-labile Protecting Groups
06:44

Hydrolysis of a Ni-Schiff-Base Complex Using Conditions Suitable for Retention of Acid-labile Protecting Groups

Published on: April 6, 2017

9.9K
Controlling the Size, Shape and Stability of Supramolecular Polymers in Water
16:24

Controlling the Size, Shape and Stability of Supramolecular Polymers in Water

Published on: August 2, 2012

18.9K
Analysis of Complex Molecules and Their Reactions on Surfaces by Means of Cluster-Induced Desorption/Ionization Mass Spectrometry
07:53

Analysis of Complex Molecules and Their Reactions on Surfaces by Means of Cluster-Induced Desorption/Ionization Mass Spectrometry

Published on: March 1, 2020

7.5K

Area of Science:

  • Analytical Chemistry
  • Mass Spectrometry
  • Coordination Chemistry

Background:

  • Ethylenediaminetetraacetic acid (EDTA) is a versatile complexation agent forming stable complexes with numerous metals.
  • EDTA finds widespread use in food, medical, and household applications due to its strong metal-binding capabilities.

Purpose of the Study:

  • To investigate the fragmentation behavior of EDTA and its metal complexes under different dissociation conditions.
  • To analyze fragmentation patterns using high-resolution mass spectrometry for elemental composition assignment.
  • To identify trends in fragmentation based on metal properties and periodic table location.

Main Methods:

  • Electrospray ionization (ESI) in both positive and negative modes.
  • Collision-induced dissociation (CID), infrared-multiphoton dissociation (IRMPD), and higher-energy collisional dissociation (HCD) activation.
  • High-resolution accurate mass analysis using ion cyclotron resonance (ICR) and Orbitrap mass spectrometers.

Main Results:

  • Characteristic fragmentation patterns were observed for EDTA and its various metal complexes.
  • High-resolution mass spectrometry enabled unambiguous assignment of elemental compositions for most fragments.
  • Fragmentation trends correlated with the size and periodic table position of the complexed metal ions.

Conclusions:

  • The study provides detailed insights into the gas-phase dissociation mechanisms of EDTA-metal complexes.
  • Mass spectrometry fragmentation analysis is a powerful tool for characterizing metal-EDTA interactions.
  • Observed trends can aid in predicting and understanding the behavior of similar complexes.
