Inkjet-Printed MoS2 Transistors with Predominantly Intraflake Transport.
Sandeep K Mondal1, Ananya Biswas2, Jyoti R Pradhan1
1Department of Materials Engineering, Indian Institute of Science (IISc), C V Raman Avenue, Bengaluru, 560012, India.
Researchers developed fully printed 2D semiconductor transistors using molybdenum disulfide (MoS2) nanosheets. Printing an additional metal layer overcomes transport limitations, enabling high performance for flexible electronics.
Area of Science:
- Materials Science
- Nanotechnology
- Electronics Engineering
Background:
- 2D semiconductors like transition metal dichalcogenides (TMDs) offer unique properties for electronics, including suitable bandgaps and mechanical flexibility.
- Solution-processed TMD nanosheets are promising for low-temperature fabrication on diverse substrates.
- Poor inter-flake transport in conventional 2D-TMD networks limits device performance.
Purpose of the Study:
- To overcome inter-flake transport limitations in 2D-TMD transistors.
- To demonstrate high-performance, fully printed field-effect transistors (FETs) using molybdenum disulfide (MoS2) nanosheets.
- To explore subthermionic transport mechanisms and device feasibility for printed electronics.
Main Methods:
- Fabrication of narrow-channel MoS2 field-effect transistors (FETs) using electrolyte-gating.
- Implementation of a printing technique with an additional metal layer to shorten effective channel lengths.
- Characterization of device performance, including current saturation, on-off ratio, and subthreshold slope.
Main Results:
- Achieved high current saturation (>310 µA µm⁻¹) and on-off ratio (>10⁶) in printed MoS2 FETs.
- Demonstrated predominant intraflake transport by reducing effective channel lengths.
- Observed subthermionic transport with a low subthreshold slope (7.5 mV dec⁻¹).
- Presented thermionic MOSFETs and fully printed NMOS inverters.
Conclusions:
- The developed printing approach effectively overcomes transport limitations in 2D-TMD network transistors.
- The generic method using chemically exfoliated nanosheet inks enables fully printed 2D-TMD electronics with high yield.
- This work highlights the potential for large-scale, low-cost manufacturing of flexible electronic devices.
