Quantifying residual elemental carbon by thermal-optical analysis using an extended IMPROVE_A protocol with higher
Xiaolu Zhang1, Krystyna Trzepla1, Warren White1
1Air Quality Research Center, University of California Davis, Davis, California, USA.
Journal of the Air & Waste Management Association (1995)
|September 7, 2022
Summary
Higher temperatures in thermal-optical analysis can better quantify elemental carbon (EC) in air samples. This improved method reveals significant residual EC missed by standard protocols, especially in urban areas.
Area of Science:
- Atmospheric chemistry and air quality monitoring
- Particulate matter analysis
- Carbonaceous aerosol quantification
Background:
- Thermal-optical analysis (TOA) is standard for measuring organic carbon (OC) and elemental carbon (EC) in air samples.
- The IMPROVE_A protocol, commonly used, may underestimate EC by not fully evolving it at 840°C.
- Residual EC in Chemical Speciation Network (CSN) samples suggests limitations in current TOA methods.
Purpose of the Study:
- To investigate operational conditions for evolving and quantifying residual elemental carbon (EC).
- To evaluate modifications to the IMPROVE_A protocol for enhanced EC detection.
- To assess the impact of higher temperatures on EC quantification in CSN samples.
Main Methods:
- Modified the IMPROVE_A protocol by introducing a higher temperature step (930°C) for EC evolution.
- Analyzed four heavily loaded CSN samples to evaluate protocol modifications.
- Applied the extended protocol to over 2600 CSN samples to quantify residual EC.
Main Results:
- A 930°C step evolved residual EC more effectively than extending the 840°C step duration.
- The modified protocol quantified additional EC, representing 7.6% to 25.1% of total carbon.
- Measurable residual EC was found in 6.4% of analyzed CSN samples, reaching up to 28% of total EC in highly loaded samples.
Conclusions:
- The standard IMPROVE_A protocol likely underestimates elemental carbon (EC) in CSN samples.
- Increasing the maximum heating temperature to 930°C improves EC quantification.
- This enhanced method is crucial for accurately assessing EC in areas affected by fresh urban emissions.
