Wear patterns in knee OA correlate with native limb geometry.

A Van Oevelen1,2,3, I Van den Borre4, K Duquesne1,2

  • 1Department of Orthopedic Surgery and Traumatology, Ghent University Hospital, Ghent, Belgium.

Frontiers in Bioengineering and Biotechnology
|December 5, 2022
PubMed
Summary

This study introduces a new method to analyze knee osteoarthritis (OA) by standardizing cartilage thickness assessment. It reveals that limb geometry and alignment significantly predict the risk and location of cartilage loss in knee OA.

Keywords:
alignmentknee diagnostic imagingknee wearosteoarthritisstatistical shape analysis

More Related Videos

In Vivo Quantification of Hip Arthrokinematics during Dynamic Weight-bearing Activities using Dual Fluoroscopy
07:43

In Vivo Quantification of Hip Arthrokinematics during Dynamic Weight-bearing Activities using Dual Fluoroscopy

Published on: July 2, 2021

3.1K
The Lower Body Positive Pressure Treadmill for Knee Osteoarthritis Rehabilitation
09:10

The Lower Body Positive Pressure Treadmill for Knee Osteoarthritis Rehabilitation

Published on: July 22, 2019

10.6K

Related Experiment Videos

Last Updated: Aug 19, 2025

Tissue Collection and RNA Extraction from the Human Osteoarthritic Knee Joint
06:06

Tissue Collection and RNA Extraction from the Human Osteoarthritic Knee Joint

Published on: July 22, 2021

6.1K
In Vivo Quantification of Hip Arthrokinematics during Dynamic Weight-bearing Activities using Dual Fluoroscopy
07:43

In Vivo Quantification of Hip Arthrokinematics during Dynamic Weight-bearing Activities using Dual Fluoroscopy

Published on: July 2, 2021

3.1K
The Lower Body Positive Pressure Treadmill for Knee Osteoarthritis Rehabilitation
09:10

The Lower Body Positive Pressure Treadmill for Knee Osteoarthritis Rehabilitation

Published on: July 22, 2019

10.6K

Area of Science:

  • Biomedical Engineering
  • Orthopedics
  • Radiology

Background:

  • Current knee osteoarthritis (OA) grading uses discrete scoring systems on predefined regions.
  • Anatomically standardized cartilage thickness assessment is crucial for robust statistical comparisons.
  • This study addresses the need for standardized analysis to understand OA risk factors.

Purpose of the Study:

  • To develop a method for anatomically standardized cartilage thickness assessment.
  • To compare morphotypes of healthy individuals and virtual reconstructions of OA patients.
  • To assess shape-related knee OA risk and correlate phenotype with cartilage loss patterns.

Main Methods:

  • Utilized a dataset of 798 end-stage knee OA cases.
  • Computed joint space width and translated it into 2D pixel images.
  • Employed a principal polynomial autoencoder for non-linear encoding of cartilage wear patterns and virtual healthy twin reconstruction.

Main Results:

  • Identified 4 dominant wear patterns accounting for 94% of variance: medial (54.8%), bicompartmental (25.2%), and lateral (9.1%).
  • Medial wear further subdivided into anteromedial (11.3%) and posteromedial (10.4%).
  • Pre-diseased limb geometry predicted OA incidence with a positive predictive value of 0.80 (r=0.58, p<0.001).

Conclusions:

  • Presented an innovative workflow to correlate cartilage wear with knee joint phenotype.
  • Assessed distinct knee OA risk based on pre-diseased lower limb morphology.
  • Confirmed the importance of alignment and joint geometry in knee OA onset and progression.
