Encapsulating therapeutic cells in RGD-modified agarose microcapsules

Current cell-based strategies for repairing damaged tissue often show limited efficacy due to low cell retention at the site of injury. Encapsulation of cells within hydrogel microcapsules demonstrably increases cell retention but benefits can be limited due to premature cell escape from the hydrogel microcapsules and subsequent clearance from the targeted tissue. We propose a method of encapsulating cells in agarose microcapsules that have been modified to increase cell retention by providing cell attachment domains within the agarose hydrogel allowing cells to adhere to the microcapsules. We covalently modified agarose with the addition of the cell adhesion peptide, RGD (arginine, glycine, aspartic acid). We then used a microfluidic platform to encapsulate single cells within 50 μm agarose microcapsules. We tracked encapsulated cells for cell viability, egress from microcapsules and attachment to microcapsules at 2 h, 24 h, and 48 h after encapsulation. Many encapsulated cells eventually egress their microcapsule. Those that were encapsulated using RGD-modified agarose adhered to the outer surface of the microcapsule following egress. NIH 3T3 cells showed nearly 45% of egressed cells attached to the outside of RGD modified agarose microcapsules, while minimal cellular adhesion was observed when using unmodified agarose. Similarly, human umbilical vein endothelial cells had up to 33% of egressed cells attached and explant-derived cardiac cells showed up to 20% attachment with the presence of RGD binding domains within the agarose microcapsules.
