Uniformly Distributed Mixed Matrix Membranes via a Solution Processable Strategy for Propylene/Propane Separation.

Area of Science:

• Materials Science
• Chemical Engineering
• Nanotechnology

Background:

• Filler particle aggregation is a major challenge in mixed matrix membranes (MMMs), limiting filler loadings to 10-15 wt% and hindering performance.
• Agglomeration of filler particles negatively impacts membrane separation efficiency and permeability.

Purpose of the Study:

• To develop a novel surface modification strategy for ZIF-67 metal-organic framework (MOF) fillers to improve their compatibility with polymer matrices.
• To synthesize highly loaded MMMs with reduced filler agglomeration and enhanced separation performance for C3H6/C3H8 mixtures.
• To investigate the underlying mechanisms of improved compatibility and separation performance using molecular dynamics simulations.

Main Methods:

• Surface modification of ZIF-67 MOF filler with Ag4tz4.
• Fabrication of mixed matrix membranes (MMMs) with modified ZIF-67.
• Gas separation performance testing for C3H6/C3H8 mixtures.
• Molecular dynamics simulations to analyze filler-polymer interactions and gas transport.

Main Results:

• Synthesized highly loaded MMMs (>15 wt% filler) with significantly reduced ZIF-67 agglomeration.
• Achieved unprecedented separation selectivity of 39 for C3H6/C3H8 mixtures with high permeability rates of 99 Barrer.
• Molecular dynamics simulations confirmed enhanced compatibility between ZIF-67 and the polymer matrix due to Ag4tz4 modification.
• Demonstrated excellent pressure and temperature resistance, with long-term stability exceeding 900 hours.

Conclusions:

• Surface modification of MOF fillers is an effective strategy to overcome agglomeration issues in MMMs.
• The developed Ag4tz4-modified ZIF-67 MMMs offer superior performance for C3H6/C3H8 separation compared to existing materials.
• This approach provides a pathway for fabricating high-performance MMMs for various gas separation applications.
