Naphthalimide-Based, Single-Chromophore, Emission Ratiometric Fluorescent Sensor for Tracking Intracellular pH.
Sujit Kumar Das1, Smitaroopa Kahali1, Sabnam Kar2
1Department of Chemical Sciences, Tata Institute of Fundamental Research, Mumbai, 400005, India.
Chembiochem : a European Journal of Chemical Biology
|July 29, 2024
Summary
Researchers developed TRapH, a novel pH sensor for tracking acidity in living cells. This cell-permeable tool enables real-time imaging and quantification of intracellular pH dynamics.
Area of Science:
- Biochemistry
- Cell Biology
- Fluorescence Imaging
Background:
- Intracellular pH (pHi) is a critical regulator of cellular processes.
- Accurate monitoring of pHi is essential for understanding cell function and disease.
- Existing pH sensors have limitations in terms of sensitivity, cell permeability, or photostability.
Purpose of the Study:
- To develop and characterize a novel, cell-permeable pH sensor for live-cell imaging.
- To enable ratiometric quantification of intracellular pH in the acidic range (~pH 3-6).
- To demonstrate the sensor's utility in tracking dynamic changes in cellular pH.
Main Methods:
- Synthesis and characterization of the novel pH sensor, TRapH.
- In vitro assessment of TRapH's pH-sensitive ratiometric emission response.
- Live-cell imaging experiments in mammalian cells to monitor intracellular pH dynamics.
- Induction of pH changes using a synthetic proton (H+) transporter.
Main Results:
- TRapH exhibits a reversible, cell-permeable nature.
- The sensor displays a pH-sensitive ratiometric emission response in the acidic range (approximately pH 3-6).
- TRapH successfully enabled real-time imaging and quantification of intracellular pH in living mammalian cells.
Conclusions:
- TRapH is a promising tool for monitoring acidic intracellular pH environments.
- The sensor facilitates the live-tracking of dynamic pH changes in response to biological stimuli.
- TRapH opens new avenues for investigating pH-dependent cellular processes.
