A structural biology compatible file format for atomic force microscopy.

Yining Jiang1,2, Zhaokun Wang2,3, Simon Scheuring4,5

  • 1Biochemistry & Structural Biology, Cell & Developmental Biology, and Molecular Biology (BCMB) Program, Weill Cornell Graduate School of Medical Sciences, New York, NY, USA.

Nature Communications
|February 15, 2025
PubMed
Summary
This summary is machine-generated.

Atomic force microscopy (AFM) data can now be converted into 3D-density files, enabling integration with other structural biology techniques. This advancement allows for visualization and analysis alongside cryo-EM, X-ray crystallography, and NMR, enhancing protein structure determination.

More Related Videos

Atomic Force Microscopy Imaging and Force Spectroscopy of Supported Lipid Bilayers
10:15

Atomic Force Microscopy Imaging and Force Spectroscopy of Supported Lipid Bilayers

Published on: July 22, 2015

14.7K
Visualization of Recombinant DNA and Protein Complexes Using Atomic Force Microscopy
08:30

Visualization of Recombinant DNA and Protein Complexes Using Atomic Force Microscopy

Published on: July 18, 2011

22.4K

Related Experiment Videos

Last Updated: May 27, 2025

Measuring the Mechanical Properties of Living Cells Using Atomic Force Microscopy
08:41

Measuring the Mechanical Properties of Living Cells Using Atomic Force Microscopy

Published on: June 27, 2013

39.9K
Atomic Force Microscopy Imaging and Force Spectroscopy of Supported Lipid Bilayers
10:15

Atomic Force Microscopy Imaging and Force Spectroscopy of Supported Lipid Bilayers

Published on: July 22, 2015

14.7K
Visualization of Recombinant DNA and Protein Complexes Using Atomic Force Microscopy
08:30

Visualization of Recombinant DNA and Protein Complexes Using Atomic Force Microscopy

Published on: July 18, 2011

22.4K

Area of Science:

  • Structural Biology
  • Biophysics
  • Computational Biology

Background:

  • Established structural biology methods like cryo-EM, X-ray crystallography, and NMR provide crucial protein structure data.
  • Atomic force microscopy (AFM) has historically lacked direct integration with these established structural biology techniques.
  • Localization AFM (LAFM) has emerged, offering high-resolution structural insights from AFM data.

Purpose of the Study:

  • To develop a pipeline for transforming AFM data into a format compatible with standard structural biology visualization and analysis tools.
  • To enable the integration of AFM data with established structural biology methods for enhanced protein structure determination.
  • To create a standardized file format for AFM data that facilitates comparison and cross-verification with other structural data.

Main Methods:

  • Development of a computational pipeline to convert AFM data into 3D-density files (.afm).
  • Utilizing 3D-LAFM densities as force fields for molecular dynamics flexible fitting (MDFF).
  • Demonstrating the visualization and analysis capabilities of the .afm file format for both conventional and LAFM images.

Main Results:

  • Successful transformation of AFM data into .afm files, readable by common structural biology software.
  • Demonstrated use of 3D-LAFM densities to guide MDFF, yielding structural models of previously unresolved states.
  • The .afm format allows for direct 3D/2D visualization and analysis of AFM images, facilitating comparison with other structural data.

Conclusions:

  • The developed pipeline and .afm file format bridge the gap between AFM and traditional structural biology methods.
  • This integration allows AFM to be routinely used alongside cryo-EM, X-ray crystallography, and NMR for protein structure studies.
  • The .afm format is anticipated to become a standard for AFM data deposition, promoting data sharing and cross-validation within the structural biology community.
