Current induced electromechanical strain in thin antipolar Ag2Se semiconductor.
Hao Luo1,2, Qi Liang1,2, Anan Guo1,2
1State Key Laboratory of Advanced Technology for Materials Synthesis and Processing, Wuhan University of Technology, Wuhan, China.
A giant electromechanical strain of 6.7% was discovered in antipolar silver selenide (Ag2Se) semiconductor. Electric current alters dipoles and induces phase transitions, enabling control over deformation and conductivity.
Area of Science:
- Materials Science
- Condensed Matter Physics
- Semiconductor Physics
Background:
- Electromechanical coupling enables energy conversion between electrical and elastic forms, crucial for various applications.
- While observed in dielectrics (piezoelectricity, electrostriction), mechanisms in narrow-bandgap semiconductors are debated.
- Previous studies noted electromechanical coupling in semiconductors, but the underlying physics in small bandgap materials remained unclear.
Purpose of the Study:
- To investigate the electromechanical coupling phenomenon in thin antipolar silver selenide (Ag2Se) semiconductor.
- To elucidate the mechanism of giant electromechanical strain induced by electric current in Ag2Se.
- To demonstrate the potential for concurrent control of electroelastic deformation and electrical conductivity.
Main Methods:
- Utilized in-situ transmission electron microscopy to measure local strain.
- Applied controlled electric current densities to thin antipolar Ag2Se samples.
- Analyzed the effects of current density on material's dipoles and phase transitions.
Main Results:
- Observed a giant electromechanical strain of 6.7% in Ag2Se.
- Identified two distinct steps: dipole alteration at low current density and phase transition at moderate current density.
- Demonstrated that electric current exhibits both thermal and athermal effects, including dipole alteration and interaction with dipole vortices.
Conclusions:
- Discovered a novel giant electromechanical strain phenomenon in Ag2Se driven by electric current.
- Established that electric current can induce significant deformation through dipole alteration and phase transitions.
- Showcased the potential of this phenomenon for applications requiring simultaneous control of mechanical strain and electrical properties.
