Granular hydrogels as brittle yield stress fluids.

G B Thompson1,2, J Lee1, K M Kamani1

  • 1Dept. Chemical and Biomolecular Engineering, University of Illinois Urbana-Champaign, Urbana, IL 61801.

Biorxiv : the Preprint Server for Biology
|March 10, 2025
PubMed
Summary
This summary is machine-generated.

Granular hydrogels exhibit complex rheology, behaving as brittle yield stress fluids. A new model quantifies their transient behavior, aiding in rational design for biomedical applications like 3D bioprinting.

Keywords:
Granular hydrogelbrittilitygranular mixturerecovery rheologyself-healing

More Related Videos

Macro-Rheology Characterization of Gill Raker Mucus in the Silver Carp, Hypophthalmichthys molitrix
09:13

Macro-Rheology Characterization of Gill Raker Mucus in the Silver Carp, Hypophthalmichthys molitrix

Published on: July 10, 2020

3.0K
Visualization of Failure and the Associated Grain-Scale Mechanical Behavior of Granular Soils under Shear using Synchrotron X-Ray Micro-Tomography
09:00

Visualization of Failure and the Associated Grain-Scale Mechanical Behavior of Granular Soils under Shear using Synchrotron X-Ray Micro-Tomography

Published on: September 29, 2019

13.2K

Related Experiment Videos

Last Updated: May 23, 2025

Fragmenting Bulk Hydrogels and Processing into Granular Hydrogels for Biomedical Applications
10:18

Fragmenting Bulk Hydrogels and Processing into Granular Hydrogels for Biomedical Applications

Published on: May 17, 2022

5.4K
Macro-Rheology Characterization of Gill Raker Mucus in the Silver Carp, Hypophthalmichthys molitrix
09:13

Macro-Rheology Characterization of Gill Raker Mucus in the Silver Carp, Hypophthalmichthys molitrix

Published on: July 10, 2020

3.0K
Visualization of Failure and the Associated Grain-Scale Mechanical Behavior of Granular Soils under Shear using Synchrotron X-Ray Micro-Tomography
09:00

Visualization of Failure and the Associated Grain-Scale Mechanical Behavior of Granular Soils under Shear using Synchrotron X-Ray Micro-Tomography

Published on: September 29, 2019

13.2K

Area of Science:

  • Materials Science
  • Rheology
  • Biomedical Engineering

Background:

  • Granular hydrogels are widely used in biomedical applications.
  • Current rheological characterization methods often focus on shear-thinning, self-healing, or ensemble metrics.
  • A need exists for detailed analysis of transient rheological behaviors during yielding and unyielding processes.

Purpose of the Study:

  • To develop and apply an analytical framework to comprehensively characterize the rheological behavior of granular hydrogels.
  • To investigate the influence of microgel and granular assembly properties on steady and transient rheology.
  • To establish a quantitative model for the rational design of granular hydrogels.

Main Methods:

  • Utilized oscillatory shear testing combined with the Kamani-Donley-Rogers (KDR) model, incorporating Brittility (Bt).
  • Quantified steady and transient rheology by varying microgel composition and diameter, and granular packing and droplet heterogeneity.
  • Analyzed mixtures of polyethylene glycol and gelatin microgels.

Main Results:

  • Granular hydrogels were characterized as brittle yield stress fluids with complex transient rheology.
  • The KDR model with Bt effectively captured granular hydrogel behavior across various design parameters.
  • Rheological behavior and model parameters were correlated with microgel composition in monolithic and mixed hydrogels.
  • Self-healing behavior was robustly captured, and granular relaxation time was found to depend on strain amplitude.

Conclusions:

  • The KDR model with Bt provides a quantitative framework for understanding and predicting granular hydrogel rheology.
  • This approach reduces complex transient rheology to manageable model parameters.
  • The findings facilitate the rational design of granular hydrogels for diverse applications, including injection, *in situ* stabilization, and 3D bioprinting.
