Multiparameter optimal control of F_{1}-ATPase.

W Callum Wareham1, David A Sivak1

  • 1Simon Fraser University, Department of Physics, Burnaby, British Columbia V5A 1S6, Canada.

Physical Review. E
|August 1, 2025
PubMed
Summary
This summary is machine-generated.

Optimal control theory guides efficient energy conversion in biological molecular machines like F1-ATPase. Dynamic control of trap parameters offers flexibility, with single-parameter control and static choices also yielding efficient protocols.

More Related Videos

A Semi-High-Throughput Adaptation of the NADH-Coupled ATPase Assay for Screening Small Molecule Inhibitors
10:28

A Semi-High-Throughput Adaptation of the NADH-Coupled ATPase Assay for Screening Small Molecule Inhibitors

Published on: August 17, 2019

9.7K
F1FO ATPase Vesicle Preparation and Technique for Performing Patch Clamp Recordings of Submitochondrial Vesicle Membranes
08:21

F1FO ATPase Vesicle Preparation and Technique for Performing Patch Clamp Recordings of Submitochondrial Vesicle Membranes

Published on: May 4, 2013

10.5K

Related Experiment Videos

Last Updated: Sep 13, 2025

Isolation of F1-ATPase from the Parasitic Protist Trypanosoma brucei
08:44

Isolation of F1-ATPase from the Parasitic Protist Trypanosoma brucei

Published on: January 22, 2019

7.4K
A Semi-High-Throughput Adaptation of the NADH-Coupled ATPase Assay for Screening Small Molecule Inhibitors
10:28

A Semi-High-Throughput Adaptation of the NADH-Coupled ATPase Assay for Screening Small Molecule Inhibitors

Published on: August 17, 2019

9.7K
F1FO ATPase Vesicle Preparation and Technique for Performing Patch Clamp Recordings of Submitochondrial Vesicle Membranes
08:21

F1FO ATPase Vesicle Preparation and Technique for Performing Patch Clamp Recordings of Submitochondrial Vesicle Membranes

Published on: May 4, 2013

10.5K

Area of Science:

  • Biophysics
  • Molecular Machines
  • Thermodynamics

Background:

  • Biological molecular machines efficiently convert free energy within cells.
  • Optimal control theory offers a framework for understanding efficient energy driving mechanisms.

Purpose of the Study:

  • To design efficient protocols for driven F1-ATPase using dynamic control of trap parameters.
  • To elucidate design principles for energetically efficient molecular machines.

Main Methods:

  • Linear-response theory applied to a model of driven F1-ATPase.
  • Dynamic control of trap center and stiffness investigated.

Main Results:

  • Efficient protocols can be achieved through dynamic control of both trap center and stiffness.
  • Alternatively, dynamic control of one parameter combined with a static choice for the other also yields efficiency.
  • The degree of performance improvement varies with the system and control strategy.

Conclusions:

  • Dynamic control offers a powerful approach to optimize energy conversion in molecular machines.
  • Flexibility in control strategies, including single-parameter dynamic control, can achieve high efficiency.
  • Understanding these principles aids in designing more efficient artificial molecular systems.
