Cryogenic light microscopy of vitrified samples with angstrom precision.
Hisham Mazal1,2, Franz-Ferdinand Wieser1,2,3, Daniel Bollschweiler4
1Max Planck Institute for the Science of Light, Erlangen 91058, Germany.
Summary
Single-particle cryogenic light microscopy (spCryo-LM) achieves near-native structural biology studies. This superresolution technique provides angstrom precision for proteins in cellular environments without fixation.
Area of Science:
- Structural Biology
- Biophysics
- Microscopy
Background:
- High-resolution structural biology is hindered by sample crystallization difficulties and low contrast in native cellular environments.
- Superresolution microscopy offers solutions but has been limited to chemically fixed samples, compromising native structure preservation.
- Achieving near-native sample preservation and near-atomic optical resolution are crucial for advancing light microscopy in structural biology.
Purpose of the Study:
- To introduce single-particle cryogenic light microscopy (spCryo-LM) as a novel technique for high-resolution structural studies.
- To enable near-native sample preservation and near-atomic optical resolution using light microscopy.
- To establish light microscopy as a versatile tool for structural biology, compatible with native cellular environments.
Main Methods:
- Adapted cryogenic electron microscopy (Cryo-EM) protocols for shock-freezing biological samples.
- Utilized a high-vacuum cryogenic shuttle system for sample transfer into a liquid-helium cryostat housing a superresolution fluorescence microscope.
- Exploited low-temperature enhanced photophysics for angstrom-precision fluorophore localization.
Main Results:
- Demonstrated angstrom precision in localizing fluorophores on proteins separated by hundreds of nanometers.
- Characterized vitreous ice, single-molecule photoblinking, and laser intensity effects at cryogenic temperatures.
- Successfully resolved the structure of alpha-hemolysin in a synthetic membrane and membrane proteins within their native cellular environment.
Conclusions:
- Single-particle cryogenic light microscopy (spCryo-LM) enables structural studies of proteins in their native cellular environment without chemical fixation or isolation.
- The technique achieves near-native sample preservation and near-atomic optical resolution, establishing light microscopy as a powerful structural biology tool.
- spCryo-LM is compatible with other superresolution and spectroscopic techniques, paving the way for correlative microscopy with Cryo-EM.
