The Alpha-SPECT-Mini: A Small-Animal SPECT System based on Hyperspectral Compound-Eye Gamma Cameras
Elena Maria Zannoni1, Can Yang2, Ling Cai2
1Walker Department of Mechanical Engineering at the University of Texas at Austin, Austin, TX 78712 USA and the work described was performed when she was at the Department of Nuclear, Plasma and Radiological Engineering, University of Illinois at Urbana-Champaign, Urbana, IL 61801 USA.
The Alpha-SPECT-Mini system provides ultrahigh energy resolution for small animal imaging. This advanced Single Photon Emission Computed Tomography (SPECT) system enables precise imaging of alpha-emitters for preclinical research.
Area of Science:
- Medical Imaging
- Nuclear Medicine
- Radiochemistry
Background:
- Growing demand for enhanced energy resolution in Single Photon Emission Computed Tomography (SPECT) systems.
- Need for multi-functional molecular imaging, including alpha-emitter radiopharmaceutical therapy (α-RPT).
Purpose of the Study:
- To design and evaluate the Alpha-SPECT-Mini system for small animal studies.
- To achieve ultrahigh energy resolution and high sensitivity for imaging alpha-emitters.
Main Methods:
- Utilized small-pixel Cadmium Telluride (CdTe) detectors for superior energy resolution.
- Employed a 96-collimator hole system and six stationary detection panels in a full ring configuration.
- Validated system performance using Tc-99m and Ac-225 filled phantoms for resolution and image quality assessment.
Main Results:
- Achieved sub-1keV Full-Width-Half-Maximum (FWHM) energy resolution for single pixel events.
- Demonstrated average energy resolutions of ~2.5keV at 122 keV and ~3.5keV at 218 keV across 153600 pixels.
- Successfully identified X- and gamma-ray contributions in complex spectra, crucial for Ac-225 decay chain analysis.
Conclusions:
- The Alpha-SPECT-Mini system exhibits high performance for imaging alpha-emitters in preclinical settings.
- The system's ultrahigh energy resolution facilitates advanced molecular imaging applications.
- Experimental validation confirms the system's capability for preclinical alpha-emitter imaging.
