Deep roots through time and crops: insight from five seasons at DeepRootLab.
Eusun Han1,2,3, Corentin Clément1, Weronika Czaban1
1Department of Plant and Environmental Sciences, University of Copenhagen, Højbakkegård Allé 13, DK-2630, Taastrup, Denmark.
The New Phytologist
|March 13, 2026
Summary
Researchers developed a novel field facility to study deep root systems in crops. This facility enables efficient analysis of root density and nutrient uptake in deep soil layers, crucial for improving crop production.
Area of Science:
- Agricultural Science
- Plant Biology
- Soil Science
Background:
- Deep-rooted crops enhance agricultural resource utilization by accessing water and nutrients from deeper soil profiles.
- Traditional field studies of deep root systems are labor-intensive, limiting comprehensive research and scope.
- Understanding deep root dynamics is critical for optimizing crop productivity and resilience.
Purpose of the Study:
- To establish and validate a field research facility for studying deep root growth and function in various crop species.
- To assess the effectiveness of minirhizotrons, AI-driven analysis, and less-invasive techniques for deep root research.
- To investigate inter-species variations in deep root density, activity, and their impact on soil resource utilization.
Main Methods:
- Installation of 48 replicated plots with 144 minirhizotron tubes (6m length) for root observation.
- Development of an AI-based pipeline for rapid analysis of root traits and architecture.
- Utilization of access tubes, ingrowth cores, 15N nutrient tracing, and time-domain reflectometry sensors for less-invasive root activity and soil water studies.
Main Results:
- Significant inter-species differences in deep root density were observed, particularly between 2.5m and 4.5m depths over a 5-year period.
- Less-invasive ingrowth core studies successfully reached depths of 4.2m, indicating root presence and activity.
- 15N tracer analysis and time-domain reflectometry revealed distinct patterns of deep root activity and water depletion influenced by crop species and root morphology.
Conclusions:
- The established field facility is effective for analyzing deep root systems of diverse plant species.
- The facility provides a robust platform for statistically and biologically significant research into deep soil layers.
- Findings support the development of agricultural strategies that leverage deep root traits for enhanced crop production and resource management.
