Quartz-Like Supramolecular Glass Enabled by Host-Guest Size Mismatch
Jianfeng Jia1, Yi Su1, Gang Ye1
1Collaborative Innovation Center of Advanced Nuclear Energy Technology, Institute of Nuclear and New Energy Technology, Tsinghua University, Beijing, China.
Abstract:
Supramolecular glasses are conventionally restricted by a fundamental trade-off between mechanical robustness and deep-ultraviolet (UV) transparency, due to the ubiquitous reliance on aromatic building blocks. Herein, we overcome this limitation by reporting a "quartz-like" supramolecular glass assembled from fully saturated aliphatic macrocycles and lithium salts, enabled by a host-guest size mismatch strategy. Crystallographic elucidation reveals that the undersized Li+ guest induces severe conformational frustration within the macrocycle, which, in concert with weak anion coordination (PF6 -), kinetically suppresses crystallization. In contrast, size-matched analogues (Na+/K+) or strongly coordinating anions (Cl-/NO3 -) assemble as ordered crystalline solids. The resulting material resolves the traditional property conflict, exhibiting fused-silica-like transparency (>95%) spanning the deep-UV to near-infrared regions, while maintaining a high Young's modulus of ∼4.85 GPa, dynamic regenerative repair capability, and robust interfacial adhesion. Notably, the glass demonstrates exceptional stability against high-intensity UV and γ-ray radiation. This study establishes mismatch-induced frustration as a versatile conceptual framework for engineering optically silent supramolecular materials that decouple mechanical strength from optical bandgap.
