Two-Dimensional UVA Dose Mapping Using a TTC-Pluronic F-127 Hydrogel Dosimeter

Monitoring ultraviolet (UV) radiation dose distribution is crucial in many fields, like medicine and materials science, but traditional point-of-care methods limit the ability to fully assess the spatial extent of the irradiated surface. This paper presents the characterisation of a two-dimensional (2D) dosimetry system based on Pluronic F-127 hydrogel matrix doped with 2,3,5-triphenyltetrazolium chloride (TTC) with respect to exposition to UVA radiation. The hydrogel matrix (25% w/w) provides both high transparency and mechanical stability, while TTC (0.1% w/w) functions as a colour precursor that undergoes irreversible reduction to form water-insoluble red formazan upon UVA exposure. The insolubility of TTC formazan ensures that the resulting colour changes remain spatially stable within the dosimeter. The study included sample preparation in flat PMMA containers and analysis of the effect of radiation field uniformity in a UVP CL-1000 exposure chamber. It was supported by application of Kodak X-Omat 100 NIF UV Film dosimetry. The actual dose distribution in the chamber was shown to be significantly heterogeneous (CV coefficient of variation of approximately 18%), which emphasises the need for 2D dosimeters for precise validation of irradiation devices. The use of flatbed scanning and dedicated image analysis software allowed obtaining precise 2D dose distribution maps. The dosimeter was characterised in the dose range of 0-5000 mJ/cm², showing a reproducible response (R² = 0.9967). A resolution test was conducted to assess the precision of geometric representation. In the final stage of the study, the suitability of the developed dosimetry system was verified under conditions simulating heterogeneous UV radiation dose distribution using patterns printed with Computer-to-Film (CtF) technology. The results showed that optical effects in printed films significantly affect UV transmission, limiting accurate dose recording for black coverage above approximately 40-50%. The results obtained confirm that the TTC-Pluronic F-127 system is an effective, simple and low-cost tool for 2D monitoring of UVA radiation, with potential applications in cosmetology, dermatology, and material ageing tests.
