有效的连续SF6/N2分离使用低成本和坚固的金属有机框架复合材料.
Jinjian Li1, Yuting Chen1, Tian Ke2
1Key Laboratory of Biomass Chemical Engineering of Ministry of Education, College of Chemical and Biological Engineering, Zhejiang University, Hangzhou, Zhejiang, China.
Nature communications
|January 13, 2025
概括
这项研究引入了新的复合颗粒和真空温度波动吸附 (VTSA) 过程,以有效地回收硫六化物 (SF). 该方法实现了高SF捕获和纯度,为传统方法提供了可持续的替代方案.
科学领域:
- 材料科学 材料科学 材料科学
- 环境科学 环境科学
- 化学工程是化学工程的重要组成部分.
背景情况:
- 物理吸收是冷蒸的可行替代方案,用于捕获硫六化物 (SF).
- 现有的吸附剂难以满足工业对SF6回收的需求.
研究的目的:
- 开发低成本的复合吸附剂和创新的真空温度波动吸附 (VTSA) 工艺.
- 为了实现从 (N2) 中超高效地回收低度SF6.
主要方法:
- 系统地调查内孔化学和工业工艺设计.
- 制造Al ((fum) @ 2%HPC和Al ((fum) @ 5%高复合颗粒.
- 在固定床吸附-脱附实验中应用两阶段VTSA过程.
主要成果:
- 实现了记录选择性 (>2×104) 和SF6动态容量 (~2.7 mmol/g).
- 证明了高的SF6生产率 (~58.7 L/kg),产量 (~96.8%),以及可回收性 (~1000个循环).
- 实现了99.91%的SF6回收,纯度为99.91%,工作能力为2.1mmol/g.
结论:
- 使用复合颗粒开发的VTSA工艺符合SF6回收的环境和操作要求.
- 与冷蒸相比,其性能优于工业氧化13X,能耗显著降低.
- 通过先进的表征和模拟,揭示了多部位结合和超快速扩散机制.
