Antigen-Capture Enzyme-Linked Immunosorbent Assay for Specific Detection of Mycoplasma pneumoniae
Published on: February 24, 2023
A 22-plex chemiluminescent microarray for pneumococcal antibodies.
Jerry W Pickering1, Justin D Hoopes, Matthew C Groll
1Associated Regional and University Pathologists, Institute for Clinical and Experimental Pathology, Salt Lake City, UT 84108, USA.
A new chemiluminescent microarray accurately measures IgG antibodies to 22 pneumococcal polysaccharide (PnPs) serotypes. This multiplexing technology offers a reliable alternative to ELISA for assessing immune responses to pneumococcal vaccines.
Area of Science:
- Immunology
- Vaccinology
- Biotechnology
Background:
- Pneumococcal polysaccharide (PnPs) vaccines are crucial for preventing pneumococcal disease.
- Accurate measurement of serotype-specific IgG antibody concentrations is essential for evaluating vaccine efficacy.
- Current methods like ELISA can be time-consuming and may not be suitable for high-throughput analysis.
Purpose of the Study:
- To develop and validate a chemiluminescent multiplexed microarray for simultaneous quantification of IgG antibodies to 22 pneumococcal serotypes.
- To compare the performance of the developed microarray with the established enzyme-linked immunosorbent assay (ELISA).
- To assess the microarray's ability to detect vaccine-induced antibody responses.
Main Methods:
- Development of a chemiluminescent multiplexed microarray assay capable of detecting IgG antibodies against 22 specific pneumococcal polysaccharide serotypes.
- Comparative analysis of the microarray against ELISA for nine selected serotypes, calculating correlation coefficients (r2).
- Evaluation of assay precision using interassay and intra-assay coefficients of variation and assessment of specificity through inhibition-of-binding studies.
Main Results:
- The microarray demonstrated high correlation with ELISA (r2 = 0.91–0.97) for the nine compared serotypes.
- The assay successfully detected significant increases (more than 4-fold) in antibody concentrations post-vaccination across all 22 serotypes.
- Excellent assay precision was observed, with mean interassay and intra-assay coefficients of variation of 7.6% and 6.0%, respectively.
- Inhibition studies confirmed high specificity, with >90% inhibition by homologous serotypes and <25% by heterologous serotypes.
Conclusions:
- The developed chemiluminescent multiplexed microarray is a highly accurate and reproducible method for quantifying IgG antibodies to 22 pneumococcal serotypes.
- This technology provides a robust and efficient alternative to ELISA for assessing immune responses to pneumococcal vaccines.
- The microarray's ability to simultaneously measure antibodies to multiple serotypes makes it valuable for vaccine efficacy studies and public health surveillance.
