Two-dimensional micron-step probe drive for laboratory plasma measurement.
1Department of Physics and Astronomy, University of California, Los Angeles, 1000 Veteran Ave., Suite 15-70, California 90095, USA.
The Review of Scientific Instruments
|December 3, 2008
Summary
We developed a new 2D magnetic probe platform for precise, high-resolution measurements of magnetic fields. This tool helps study magnetic interactions in experiments like those at the Large Plasma Device facility.
Area of Science:
- Plasma Physics
- Magnetohydrodynamics
- Experimental Diagnostics
Background:
- Measuring small-scale magnetic phenomena over large areas is difficult.
- Precise diagnostics are needed for studying complex plasma interactions.
Purpose of the Study:
- To present a novel 2D magnetic probe platform for high-resolution magnetic field measurements.
- To demonstrate its application in studying laser-produced plasma interactions.
Main Methods:
- Developed a 2D magnetic probe platform with sub-millimeter spatial resolution.
- Utilized a precise, repeatable positioning system.
- Applied cross-correlation techniques to analyze interaction data.
Main Results:
- Successfully measured magnetic fields over a 36 cm(2) area with sub-millimeter resolution.
- Enabled detailed analysis of magnetic interactions between counterpropagating plasmas.
- Demonstrated the platform's utility in a Large Plasma Device experiment.
Conclusions:
- The novel 2D magnetic probe platform offers a significant advancement in diagnosing small-scale magnetic phenomena.
- This technology facilitates the study of intricate magnetic interactions in laboratory plasmas.
- The platform's precision and repeatability are key for advanced data analysis techniques.
