Viscoelastic property mapping with contact resonance force microscopy.

J P Killgore¹, D G Yablon, A H Tsou

¹National Institute of Standards and Technology, Boulder, Colorado 80305, USA.

Langmuir : the ACS Journal of Surfaces and Colloids

|November 8, 2011

Summary

Contact resonance force microscopy accurately maps nanoscale viscoelastic properties of polymer blends. Results align with dynamic mechanical analysis, validating the technique for material characterization.

More Related Videos

AFM-based Mapping of the Elastic Properties of Cell Walls: at Tissue, Cellular, and Subcellular Resolutions

AFM-based Mapping of the Elastic Properties of Cell Walls: at Tissue, Cellular, and Subcellular Resolutions

Published on: July 24, 2014

Characterizing Multiscale Mechanical Properties of Brain Tissue Using Atomic Force Microscopy, Impact Indentation, and Rheometry

Characterizing Multiscale Mechanical Properties of Brain Tissue Using Atomic Force Microscopy, Impact Indentation, and Rheometry

Published on: September 6, 2016

Related Experiment Videos

Last Updated: May 27, 2026

Measuring the Mechanical Properties of Living Cells Using Atomic Force Microscopy

Measuring the Mechanical Properties of Living Cells Using Atomic Force Microscopy

Published on: June 27, 2013

AFM-based Mapping of the Elastic Properties of Cell Walls: at Tissue, Cellular, and Subcellular Resolutions

AFM-based Mapping of the Elastic Properties of Cell Walls: at Tissue, Cellular, and Subcellular Resolutions

Published on: July 24, 2014

Characterizing Multiscale Mechanical Properties of Brain Tissue Using Atomic Force Microscopy, Impact Indentation, and Rheometry

Characterizing Multiscale Mechanical Properties of Brain Tissue Using Atomic Force Microscopy, Impact Indentation, and Rheometry

Published on: September 6, 2016

Area of Science:

Materials Science
Polymer Science
Nanotechnology

Background:

Understanding near-surface viscoelastic properties is crucial for polymer blend performance.
Traditional methods often lack the nanoscale resolution required for detailed characterization.

Purpose of the Study:

To demonstrate accurate nanoscale mapping of viscoelastic properties (loss and storage moduli) in a polystyrene-polypropylene blend.
To evaluate two data acquisition methods: discrete stepping and continuous scanning.

Main Methods:

Utilized contact resonance force microscopy (CR-FM) to probe viscoelasticity.
Extracted spatially resolved maps of contact resonance frequency and quality factor from the AFM cantilever.
Compared CR-FM data with dynamic mechanical analysis (DMA) measurements.

Main Results:

Achieved accurate nanoscale mapping of near-surface loss and storage moduli.
Demonstrated good agreement between CR-FM and time-temperature superposition of DMA for point mapping and low-speed scanning.
Validated the ability to correlate low-frequency DMA with high-frequency CR-FM measurements.

Conclusions:

CR-FM is a powerful technique for nanoscale viscoelastic property mapping of polymer blends.
The data acquisition method impacts the accuracy and agreement with lower-frequency measurements.
CR-FM provides valuable insights into the heterogeneous mechanical behavior of polymer blends at the nanoscale.
