Germanium Based Field-Effect Transistors: Challenges and Opportunities.
Patrick S Goley1, Mantu K Hudait2
1Advanced Devices & Sustainable Energy Laboratory (ADSEL), Bradley Department of Electrical and Computer Engineering, Virginia Tech, Blacksburg, VA 24061, USA. patrick.goley@vt.edu.
Materials (Basel, Switzerland)
|August 10, 2017
Summary
Germanium (Ge) shows promise as a high-mobility alternative to silicon (Si) for advanced transistors. Overcoming integration and gate stack challenges is key for Ge to enable ultra-low-power, high-speed electronics.
Area of Science:
- Materials Science and Engineering
- Semiconductor Device Physics
- Microelectronics
Background:
- Strained silicon (Si) performance in metal-oxide-semiconductor field-effect transistors (MOSFETs) is nearing its limit.
- New high-carrier-mobility materials are crucial for developing ultra-low-power and high-speed microelectronic devices.
- Germanium (Ge) has emerged as a leading candidate material for next-generation transistors.
Purpose of the Study:
- To review the primary challenges hindering the widespread adoption of germanium (Ge) in semiconductor devices.
- To compare the performance of Ge-based p-channel devices with III-V compound semiconductors.
- To discuss the current state and future outlook of Ge-based transistor technology.
Main Methods:
- Review of existing literature on heterogeneous integration of Ge on Si substrates.
- Analysis of gate stack development for Ge-based transistors.
- Comparative performance analysis of Ge and III-V materials for p-channel MOSFETs.
- Examination of various Ge device architectures, including surface channel and quantum well configurations.
Main Results:
- Identified heterogeneous integration and gate stack development as critical hurdles for Ge devices.
- Established Ge as a preferred material for p-channel Metal-Oxide-Semiconductor Field-Effect Transistors (PMOS) due to its superior performance compared to III-V materials.
- Reviewed state-of-the-art Ge device results, highlighting significant advancements.
Conclusions:
- Germanium (Ge) is a promising material for future high-performance, low-power transistors.
- Addressing integration and gate stack challenges is essential for Ge to supplant Si.
- Continued research into Ge device architectures and fabrication processes will drive innovation in microelectronics.
