An Ultracompact Angular Displacement Sensor Based on the Talbot Effect of Optical Microgratings.
Zhiyong Yang1,2,3, Xiaochen Ma1, Daguo Yu2
1School of Instrument and Electronics, North University of China, Taiyuan 030051, China.
Sensors (Basel, Switzerland)
|February 11, 2023
Summary
This study introduces an ultracompact angular displacement sensor using optical microgratings and the Talbot effect. The sensor demonstrates tunable sensitivity and a wide linear range, showing promise for various engineering applications.
Area of Science:
- Optics and Photonics
- Sensor Technology
- Microfabrication
Background:
- The Talbot effect describes the self-imaging of periodic structures under coherent illumination.
- Angular displacement sensors are crucial for precise control in many engineering fields.
- Existing sensors often face limitations in size, sensitivity, or range.
Purpose of the Study:
- To develop an ultracompact angular displacement sensor.
- To investigate the Talbot effect for angular sensing applications.
- To explore the tunability of sensor performance through grating parameters.
Main Methods:
- Utilized the Talbot effect with two cascaded optical microgratings.
- Analyzed the linear relationship between transmission and relative angular displacement.
- Performed simulations and experiments to study grating parameter influences.
- Characterized sensor sensitivity and linear range.
Main Results:
- Achieved an approximate linear relationship between transmission and angular displacement.
- Demonstrated tunable sensitivity and measurement range by altering grating parameters.
- Experimentally obtained a sensitivity of 0.19 mV/arcsec and a linear range of ±396 arcsec.
- Showcased the sensor's ultracompact structure.
Conclusions:
- The proposed two-grating sensor effectively measures angular displacement based on the Talbot effect.
- Grating parameter optimization allows for tailored sensor performance.
- The sensor's compact design and tunable properties offer significant potential for aviation, navigation, robotics, and manufacturing.
