Assessing ulnar neuropathy at the elbow using magnetoneurography
Yuta Tanaka1, Toru Sasaki1, Shigenori Kawabata2
1Department of Orthopedic Surgery, Graduate school of Medical and Dental Sciences, Tokyo Medical and Dental University, 1-5-45 Yushima, Bunkyo-ku, Tokyo 113-8510, Japan.
Objective:
To measure neuromagnetic fields of ulnar neuropathy patients at the elbow after electrical stimulation and evaluate ulnar nerve function at the elbow with high spatial resolution.
Methods:
A superconducting quantum interference device magnetometer system recorded neuromagnetic fields of the ulnar nerve at the elbow after electrical stimulation at the wrist in 16 limbs of 16 healthy volunteers and 21 limbs of 20 patients with ulnar neuropathy at the elbow. After artifact removal, neuromagnetic field signals were processed into current distributions, which were superimposed onto X-ray images for visualization.
Results:
Based on the results in healthy volunteers, conduction velocity of 30 m/s or 50% attenuation in current amplitude was set as the reference value for conduction disturbance. Of the 21 patient limbs, 15 were measurable and lesion sites were detected, whereas 6 limbs were unmeasurable due to weak neuromagnetic field signals. Seven limbs were deemed normal by nerve conduction study, but 5 showed conduction disturbances on magnetoneurography.
Conclusions:
Measuring the magnetic field after nerve stimulation enabled visualization of neurophysiological activity in patients with ulnar neuropathy at the elbow and evaluation of conduction disturbances.
Significance:
Magnetoneurography may be useful for assessing lesion sites in patients with ulnar neuropathy at the elbow.
