Wearable Smart Silicone Belt for Human Motion Monitoring and Power Generation.

Area of Science:

• Materials Science
• Wearable Technology
• Energy Harvesting

Background:

• Human physical activity monitoring is vital for personalized health management.
• Existing wearable sensors often require external power sources, limiting their practicality.
• Harvesting kinetic energy from body motion offers a sustainable power solution for wearables.

Purpose of the Study:

• To develop a belt-type wearable sensor (BWS) for monitoring physical activity and harvesting mechanical energy.
• To utilize a triboelectric nanogenerator (TENG) for efficient energy conversion.
• To demonstrate the self-powered capabilities of the BWS for charging electronic devices.

Main Methods:

• Designed and fabricated a BWS using a soft silicone sheet and triboelectric polymer materials (PTFE and PA).
• Conducted a parameter study to optimize the structure and performance of the sensing units.
• Manufactured a five-unit BWS to record and differentiate various physical activities and breathing patterns.

Main Results:

• The optimized BWS unit achieved a maximum output voltage of 47 V and a maximum current of 0.17 μA.
• The BWS successfully distinguished between different physical activities (stillness, walking, running, jumping) and breathing states (normal, cessation, deep).
• The developed BWS demonstrated the ability to power electronic devices, including a smartphone, digital watch, and LED lights.

Conclusions:

• The developed belt-type wearable sensor effectively monitors human physical activity and harvests kinetic energy.
• The self-powered BWS shows potential for practical applications in personalized health management and wearable electronics.
• This work presents a novel strategy for creating self-powered intelligent wearable devices.
