Related Concept Videos

MOS Capacitor01:25

MOS Capacitor

663
A Metal-Oxide-Semiconductor (MOS) capacitor is a fundamental structure used extensively in semiconductor device technology, particularly in the fabrication of integrated circuits and MOSFETs (metal-oxide-semiconductor field-effect transistors). The MOS capacitor consists of three layers: a metal gate, a dielectric oxide, and a semiconductor substrate.
The metal gate is typically made from highly conductive materials such as aluminum or polysilicon. Beneath the metal gate lies a thin layer of...
663
MOSFET01:16

MOSFET

402
The Metal-Oxide-Semiconductor Field-Effect Transistor (MOSFET) plays a pivotal role in modern electronics thanks to its versatility and efficiency in controlling electrical currents. This device, also known as IGFET, MISFET, and MOSFET, has three main terminals: the Source, Drain, and Gate. MOSFETs are classified into n-channel or p-channel types based on the doping characteristics of their substrate and the source or drain regions.
In an n-MOSFET, the structure includes n-type source and drain...
402
Metal-Semiconductor Junctions01:24

Metal-Semiconductor Junctions

272
The contact of metal and semiconductor can lead to the formation of a junction with either Schottky or Ohmic behavior.
Schottky Barriers
Schottky barriers arise when a metal with a work function (Φm) contacts a semiconductor with a different work function (Φs). Initially, electrons transfer until the Fermi levels of the metal and semiconductor align at equilibrium. For instance, if Φm > Φs, the semiconductor Fermi level is higher than the metal's before contact. The...
272
MOSFET: Enhancement Mode01:22

MOSFET: Enhancement Mode

258
Enhancement-mode MOSFETs are pivotal components in electronics, distinguished by their capacity to act as highly efficient switches. They are part of the larger family of metal-oxide Semiconductor Field-Effect Transistors (MOSFETs). They are available in two types: p-channel and n-channel, each tailored to specific polarity operations.
In their basic form, enhancement-mode MOSFETs are typically non-conductive when the gate-source voltage (Vgs) is zero. This default 'off' state means no...
258
Characteristics of MOSFET01:17

Characteristics of MOSFET

316
Metal-oxide-semiconductor field-effect Transistors, or MOSFETs, play a critical role in electronic circuits. They are primarily utilized for amplifying and switching signals.
Various vital parameters influence their functionality, which is crucial for theory and electronics applications. First, channel dimensions, precisely length, and width, are pivotal. The size of these channels affects the transistor's ability to carry current and switching speeds; shorter channels typically enable...
316
Design Example: Resistive Touchscreen01:14

Design Example: Resistive Touchscreen

271
A device engineer plays a crucial role in designing user interfaces for mobile devices. One such interface is the resistive touchscreen, which fundamentally consists of two metallic layers: a flexible upper layer and a rigid lower layer, separated by a narrow gap. The high resistance between these two layers is a key characteristic of this design.
When a user touches the screen, the two layers make contact at a specific point known as the touchpoint. This contact reduces the resistance between...
271
