The Conceptual Design of a Variable Camber Wing.

Spencer Troy P Cortez1, Seksan Winyangkul2, Suwin Sleesongsom1

  • 1Department of Aeronautical Engineering, International Academy of Aviation Industry, King Mongkut's Institute of Technology Ladkrabang, Bangkok 10520, Thailand.

Summary

This study presents a novel three-step design for a variable camber wing (VCW) to improve unmanned aerial vehicle (UAV) performance. The method integrates aerodynamic analysis, mechanism synthesis, and structural testing for advanced morphing aircraft.
