Overcoming Asymmetric Carrier Injection in III-Nitride Light-Emitting Diodes through Defect Engineering.

Yuxin Yang1,2, Zhiming Shi1,2, Shunpeng Lv1,2

  • 1State Key Laboratory of Luminescence Science and Technology, Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China.

PubMed
Summary

Introducing nitrogen vacancies in LEDs significantly improves carrier injection by reducing electron relaxation time. This defect engineering approach addresses a key challenge in GaN-based light sources.
