Substrate-Mediated Fluorination of Graphene Directs Biointerface Chemistry and Cellular Interactions.

Gabriel Moreira1,2, Beatriz Silva1,2, Tiago Abreu1,2

  • 1International Iberian Nanotechnology Laboratory, 4715-330 Braga, Portugal.

ACS Applied Materials & Interfaces
|October 14, 2025
PubMed
Summary
This summary is machine-generated.

Chemical functionalization of graphene using xenon difluoride fluorination reprograms its surface properties. This substrate-controlled approach enhances protein adsorption and promotes cancer cell adhesion, overcoming graphene

Keywords:
2D materialscell adhesion and proliferationfunctionalizationhuman breast cancer epithelial cellspolyethylene terephthalatesiliconsilicon dioxidewettability

More Related Videos

Graphene Coatings for Biomedical Implants
13:21

Graphene Coatings for Biomedical Implants

Published on: March 1, 2013

21.7K
Graphene Enclosure of Chemically Fixed Mammalian Cells for Liquid-Phase Electron Microscopy
10:12

Graphene Enclosure of Chemically Fixed Mammalian Cells for Liquid-Phase Electron Microscopy

Published on: September 21, 2020

7.5K

Related Experiment Videos

Last Updated: Jan 15, 2026

Development and Functionalization of Electrolyte-Gated Graphene Field-Effect Transistor for Biomarker Detection
07:51

Development and Functionalization of Electrolyte-Gated Graphene Field-Effect Transistor for Biomarker Detection

Published on: February 1, 2022

3.8K
Graphene Coatings for Biomedical Implants
13:21

Graphene Coatings for Biomedical Implants

Published on: March 1, 2013

21.7K
Graphene Enclosure of Chemically Fixed Mammalian Cells for Liquid-Phase Electron Microscopy
10:12

Graphene Enclosure of Chemically Fixed Mammalian Cells for Liquid-Phase Electron Microscopy

Published on: September 21, 2020

7.5K

Area of Science:

  • Materials Science
  • Biomedical Engineering
  • Surface Chemistry

Background:

  • Pristine graphene's inert surface chemistry and hydrophobicity limit its use in biomedical applications by restricting protein adsorption and cellular interactions.
  • Chemical functionalization is crucial for modifying graphene's interfacial properties and enhancing its biocompatibility.

Purpose of the Study:

  • To demonstrate xenon difluoride fluorination as a versatile strategy for engineering graphene's interfacial properties and cellular response.
  • To investigate substrate-mediated fluorination effects on graphene's surface chemistry, wettability, and biological interactions.

Main Methods:

  • Chemical Vapor Deposition (CVD) monolayer graphene was fluorinated using xenon difluoride (XeF2).
  • Fluorination was performed on different substrates (SiO2, Si, PET) to achieve substrate-controlled, single-sided, double-sided, or polymer-coupled functionalization.
  • Surface characterization included Raman spectroscopy, X-ray Photoelectron Spectroscopy (XPS), Atomic Force Microscopy (AFM), and contact angle measurements.
  • Protein adsorption and breast cancer cell adhesion/proliferation assays were conducted on pristine and fluorinated graphene surfaces.

Main Results:

  • Substrate-dependent fluorination yielded diverse surface chemistries and wettability: hydrophobic SiO2/FGr (~88°), superhydrophilic Si/FGr (~15°), and tunable PET/FGr (47-78°).
  • C-F bond formation and resultant polar functional groups, not surface roughness, were identified as key drivers of wettability changes.
  • Fluorinated graphene surfaces exhibited enhanced protein adsorption and promoted breast cancer cell adhesion and proliferation compared to pristine graphene.

Conclusions:

  • Substrate-controlled xenon difluoride fluorination effectively reprograms graphene's surface chemistry and wettability.
  • Engineered graphene surfaces overcome inherent bioinertness, enhancing protein adsorption and promoting cellular interactions.
  • This approach offers versatile pathways for developing advanced graphene-based biomedical devices.
