Dual-pilot phase recovery with pair-wise maximum-ratio combining for coherent PONs.

Chen Ding, Yutian Liu, Qiarong Xiao

    Optics Letters
    |June 15, 2026
    PubMed
    Summary
    This summary is machine-generated.

    We developed a digital signal processing framework for passive optical networks using Non-Orthogonal Multiple Access (NOMA) and Digital Subcarrier Multiplexing (DSCM). This enhances carrier-phase recovery and signal quality, improving data transmission reliability.

    More Related Videos

    Combined Invasive Subcortical and Non-invasive Surface Neurophysiological Recordings for the Assessment of Cognitive and Emotional Functions in Humans
    08:25

    Combined Invasive Subcortical and Non-invasive Surface Neurophysiological Recordings for the Assessment of Cognitive and Emotional Functions in Humans

    Published on: May 19, 2016

    Related Experiment Videos

    Last Updated: Jun 17, 2026

    Differential Imaging of Biological Structures with Doubly-resonant Coherent Anti-stokes Raman Scattering (CARS)
    12:56

    Differential Imaging of Biological Structures with Doubly-resonant Coherent Anti-stokes Raman Scattering (CARS)

    Published on: October 17, 2010

    Combined Invasive Subcortical and Non-invasive Surface Neurophysiological Recordings for the Assessment of Cognitive and Emotional Functions in Humans
    08:25

    Combined Invasive Subcortical and Non-invasive Surface Neurophysiological Recordings for the Assessment of Cognitive and Emotional Functions in Humans

    Published on: May 19, 2016

    Area of Science:

    • Optical Communications
    • Digital Signal Processing

    Background:

    • Non-orthogonal multiple access (NOMA) combined with digital subcarrier multiplexing (DSCM) offers dense and flexible coherent passive optical networks (PONs).
    • NOMA signal superposition introduces biases in pilot-aided carrier-phase recovery (CPR), and bandwidth limitations affect edge subcarriers.

    Purpose of the Study:

    • To propose a unified digital signal processing (DSP) framework to address NOMA-induced phase bias and transceiver limitations in coherent PONs.
    • To improve the robustness and performance of carrier-phase recovery and signal detection in NOMA-DSCM systems.

    Main Methods:

    • A unified DSP framework incorporating dual-pilot CPR with pair-wise maximum-ratio combining (MRC) across adjacent subcarrier pairs.
    • Inserting pilots into both NOMA signals to create a composite pilot reference, suppressing interference-induced phase bias.
    • Utilizing a reliability estimate for weighting subcarrier branches in MRC to achieve diversity gain.

    Main Results:

    • The dual-pilot CPR demonstrated more robust phase recovery compared to conventional methods under NOMA interference.
    • The proposed framework achieved up to 2.29 dB Signal-to-Interference-plus-Noise Ratio (SINR) gain at low optical power.
    • Average Bit Error Rate (BER) was reduced by 75.89% for ONU 1 and 30.33% for ONU 2.

    Conclusions:

    • The proposed unified DSP framework effectively mitigates NOMA-induced phase bias and transceiver penalties in coherent PONs.
    • Dual-pilot CPR and MRC significantly enhance phase recovery robustness and overall system performance.
    • The framework offers substantial SINR gain and BER reduction, enabling more reliable data transmission in high-density optical networks.
