Temporal Bone Measurements; A Comparison Between Rendered Spiral CT and Surgery.
Jahanbakhsh Hashemi1, Mohsen Rajati2, Lida Rezayani1
1Department of Radiology, Faculty of Medicine, Emam Reza Hospital, Mashhad University of Medical Sciences, Mashhad, Iran.
Summary
Computed tomography (CT) scans of the temporal bone provide measurements similar to direct surgical findings for most anatomical landmarks. This aids in precise surgical planning and reduces risks during ear surgery.
Area of Science:
- Neurosurgery
- Radiology
- Otolaryngology
Background:
- Accurate radiological assessment of temporal bone anatomy is vital for surgical safety.
- Preoperative knowledge of temporal bone landmarks aids surgical planning.
Purpose of the Study:
- To compare measurements from computed tomography (CT) scans with direct intraoperative findings.
- To evaluate the accuracy of CT in depicting key temporal bone anatomical features relevant to surgery.
Main Methods:
- Spiral CT scans of the temporal bone were performed on patients undergoing ear surgery.
- Key distances were measured by a radiologist on CT and by the surgeon intraoperatively.
- Measurements included: ear canal to sigmoid sinus, lateral semicircular canal dome to mastoid cortex, and incus to mastoid cortex.
Main Results:
- Twenty cases were analyzed.
- A significant difference was found only in the measurement of the distance between the ear canal and the sigmoid sinus.
- No significant differences were observed for the other two measured parameters.
Conclusions:
- Spiral CT measurements of temporal bone anatomy correlate well with direct surgical measurements.
- CT imaging offers a reliable method for assessing temporal bone structures prior to surgery.
