In-Depth Study of Laser Diode Ablation of Kapton Polyimide for Flexible Conductive Substrates.

Francisco J Romero1, Alfonso Salinas-Castillo2, Almudena Rivadeneyra3

  • 1Pervasive Electronics Advanced Research Laboratory (PEARL), Department of Electronics and Computer Technology, University of Granada, 18071 Granada, Spain. franromero@ugr.es.

Nanomaterials (Basel, Switzerland)
|July 13, 2018
PubMed
Summary
This summary is machine-generated.

Laser ablation enhances Kapton® polyimide conductivity by creating graphene-derived structures. This eco-friendly method significantly boosts electrical properties, offering a viable alternative for advanced material applications.

Keywords:
contact resistanceflexible electronicslaser-induced graphenelaser-scribingpolyimidesheet resistance

More Related Videos

Laser Ablation of the Zebrafish Pronephros to Study Renal Epithelial Regeneration
07:27

Laser Ablation of the Zebrafish Pronephros to Study Renal Epithelial Regeneration

Published on: August 29, 2011

15.7K
Fabrication of Nano-engineered Transparent Conducting Oxides by Pulsed Laser Deposition
10:27

Fabrication of Nano-engineered Transparent Conducting Oxides by Pulsed Laser Deposition

Published on: February 27, 2013

16.0K

Related Experiment Videos

Last Updated: Feb 7, 2026

Laser Ablation and Intravital Microscopy to Study Intestinal Remodeling
09:42

Laser Ablation and Intravital Microscopy to Study Intestinal Remodeling

Published on: June 9, 2023

2.1K
Laser Ablation of the Zebrafish Pronephros to Study Renal Epithelial Regeneration
07:27

Laser Ablation of the Zebrafish Pronephros to Study Renal Epithelial Regeneration

Published on: August 29, 2011

15.7K
Fabrication of Nano-engineered Transparent Conducting Oxides by Pulsed Laser Deposition
10:27

Fabrication of Nano-engineered Transparent Conducting Oxides by Pulsed Laser Deposition

Published on: February 27, 2013

16.0K

Area of Science:

  • Materials Science
  • Nanotechnology
  • Surface Engineering

Background:

  • Kapton® polyimide is a widely used material, but its electrical conductivity is limited for certain applications.
  • Enhancing the electrical conductivity of polyimides is crucial for developing advanced electronic components.
  • Laser-based methods offer potential for precise surface modification and property enhancement.

Purpose of the Study:

  • To investigate the photothermal ablation of Kapton® polyimide using a laser diode.
  • To enhance the electrical conductivity of polyimide films through laser treatment.
  • To characterize the induced graphene-derived structures and optimize the ablation process.

Main Methods:

  • Photothermal ablation of Kapton® polyimide with a laser diode.
  • Structural characterization using SEM, Raman spectroscopy, XPS, and DRIFT spectroscopy.
  • Electrical characterization via the Transmission Line Method (TLM) to measure conductivity and contact resistance.

Main Results:

  • Laser-assisted ablation creates graphene-derived structures on the polyimide surface.
  • Optimized laser ablation increases sample conductivity by up to six orders of magnitude.
  • Contact resistance was reduced to approximately 2 Ω using silver-based electrodes.

Conclusions:

  • Laser-assisted ablation is a simple, one-step, and environmentally friendly method for inducing conductive graphene-derived structures on polyimide.
  • The enhanced conductivity is comparable to graphene produced by chemical vapor deposition or graphene oxide reduction.
  • This technique provides a promising route for developing conductive polyimide-based materials with tunable electrical properties.
